Grade 1 and Grade 0 Safety Power System Basis Chip with CAN Flexible Data Transceiver

FS6500 Active

Roll over image to zoom in

The FS65 system basis chip (SBC) provides power to MCUs and optimizes energy consumption through DC-DC switching regulators, linear regulators and ultra-low-power saving modes.

Featuring:

  • Advanced functional safety measures to target ASIL B/D applications
  • A serial peripheral interface (SPI) to allow control and diagnostics with the MCU
  • Integration of CAN FD and LIN physical interfaces compliant with the ISO 11898-2,-5, LIN 2.2, 2.1 /J2602-2 standards along with the latest automotive OEM standards for EMC and ESD
  • A range of integrated safety features such as monitoring of critical analog parameters, a fail-safe state machine and an advanced watchdog reduce software complexity with dual-core lock-step MCUs
  • High-temperature capability up to TA = 150 °C and TJ = 175 °C, compliant with AEC-Q100 Grade 0 automotive qualification

Block Diagram

FS6500 Fail Silent SBC with DCDC, ASIL B/D ready

FS6500 Fail Silent SBC with DCDC, ASIL B/D ready
Get diagram PDF

Features

MC33FS6500xxx (Grade 1 Automotive) Features

  • MC33FS6500xxx are compliant with Grade 1 automotive qualification (up to TA=125 °C and TJ=150 °C)
  • Battery voltage sensing and MUX output pin
  • Highly flexible SMPS pre-regulator, allowing two topologies: non-inverting buck-boost and standard buck
  • The family of devices to supply MCU core from 1.0 V to 5.0 V, with SMPS (0.8 A, 1.5 A or 2.2 A) or LDO (0.5 A)
  • 36 V maximum input operating voltage
  • Linear voltage regulator dedicated to auxiliary functions, or to sensor supply (VCCA tracker or independent), 5.0 V or 3.3 V
  • Linear voltage regulator dedicated to MCU A/D reference voltage or I/Os supply (VCCA), 5.0 V or 3.3 V
  • 3.3 V keep alive memory supply available in low-power mode
  • Long duration timer, counting up to 6 months with 1.0 s resolution
  • * Multiple wake-up sources in low-power mode: CAN, LIN, IOs, LDT (Long Duration Timer)
  • Five configurable I/Os
  • MC33FS6500xxx datasheet

MC35FS6500xxx (Grade 0 Automotive) Features

  • High-temperature capability up to TA = 150 °C and TJ = 175 °C, compliant with AECQ100 Grade 0 automotive qualification
  • Battery voltage sensing and MUX output pin
  • Highly flexible SMPS pre-regulator, allowing two topologies: non-inverting buck-boost and standard buck
  • The family of devices to supply MCU core from 1.0 V to 5.0 V, with SMPS (0.8 A or 1.5 A) or LDO (0.5 A)
  • Linear voltage regulator dedicated to auxiliary functions, or to sensor supply (VCCA tracker or independent), 5.0 V or 3.3 V
  • Linear voltage regulator dedicated to MCU A/D reference voltage or I/Os supply (VCCA), 5.0 V or 3.3 V
  • 3.3 V keep alive memory supply available in low-power mode
  • Long duration timer, counting up to 6 months with 1.0 s resolution
  • Multiple wake-up sources in low-power mode: CAN, IOs, LDT (Long Duration Timer)
  • Five configurable I/Os
  • MC35FS6500xxx short datasheet

Recommended Supersets for ASIL B Only

table>
Part Number FS1B [1] LDT [2] CAN LIN Preferred superset PN w/ Linear VCORE Preferred superset PN w/ DC-DC VCORE
FS45/FS65x5NAE No No No No FS4507L or FS4508C FS6527L or FS6528C
FS45/FS65x5CAE No No Yes No FS4507L or FS4508C FS6527L or FS6528C
FS45/FS65x5KAE No No No Yes FS4507L FS6527L
FS45/FS65x5LAE No No Yes Yes FS4507L FS6527L
FS45/FS65x6NAE Yes No No No FS4508C FS6528C
FS45/FS65x6CAE Yes No Yes No FS4508C FS6528C
FS45/FS65x7NAE No Yes No No FS4507L or FS4508C FS6527L or FS6528C
FS45/FS65x7CAE No Yes Yes No FS4507L or FS4508C FS6527L or FS6528C
FS45/FS65x7KAE No Yes No Yes FS4507L FS6527L
FS45/FS65x7LAE No Yes Yes Yes FS4507L FS6527L
FS45/FS65x8NAE Yes Yes No No FS4508C FS6528C
FS45/FS65x8CAE Yes Yes Yes No FS4508C FS6528C

[1] Secondary safety output. LIN and FS1B functions are exclusive. The differentiation is made by part numbers. When LIN is available, FS1B is not and vice versa.

[2] Long duration timer.

Recommended Supersets for ASIL D Only

Part Number FS1B [1] LDT [2] VKAM On CAN LIN Preferred superset PN w/ Linear VCORE Preferred superset PN w/DC-DC VCORE
FS45/FS65x0NAE No No by SPI No No MC33FS4502LAE MC33FS6522LAE
FS45/FS65x0CAE No No by SPI Yes No
FS45/FS65xOLAE No No by SPI Yes Yes
FS45/FS65x1NAE Yes No by SPI No No MC33FS4503CAE MC33FS6523CAE
FS45/FS65x1CAE Yes No by SPI Yes No
FS45/FS65x2NAE No Yes by SPI No No MC33FS4502LAE MC33FS6522LAE
FS45/FS65x2CAE No Yes by SPI Yes No
FS45/FS65x2LAE No Yes by SPI Yes Yes
FS45/FS65x3NAE Yes Yes by SPI No No MC33FS4503CAE MC33FS6523CAE
FS45/FS65x3CAE Yes Yes by SPI Yes No
FS65x4LAE No Yes by default Yes Yes - MC33FS6524LAE

[1] Secondary safety output. LIN and FS1B functions are exclusive. The differentiation is made by part numbers. When LIN is available, FS1B is not and vice versa.

[2] Long duration timer.
