i.MX-RT1060: i.MX RT1060: Crossover MCU with Arm® Cortex®-M7

Features

Processor

MIMXRT1062DVL6B processor

Memory

256 Mb SDRAM memory
512 Mb Hyper Flash
64 Mb QSPI Flash
TF socket for SD card

Display and Audio

Parallel LCD connector
Camera connector
Audio codec
4-pole audio headphone jack
External speaker connection
Microphone
S/PDIF connector

Connectivity

Micro USB host and OTG connectors
Ethernet (10/100M) connector
CAN transceiver
Arduino^® interface

Software and support application development

MCUXpresso SDK with optional FreeRTOS support
MCUXpresso IDE
MCUXpresso Config Tools
Supported by Zephyr OS

Buy Options

Click to expand

MIMXRT1060-EVKB
Active
i.MX RT1060 Evaluation Kit.
Kit Contains:
- MIMXRT1060-EVKB board

$113.85 USD
For a quantity of 1
- Availability: In Stock
- Inventory: 26
- Shipping: Normally ships 1-2 business days

ADD TO CART
