TJA1101B, IEEE 100BASE-T1 Compliant Automotive Ethernet PHY Transceiver

TJA1101 Active

Roll over image to zoom in

TJA1101B is the revision of the successful TJA1101A. The high performance, single port automotive Ethernet PHY is compliant to IEEE 100BASE-T1. The device is passing all state of the art conformance test specs, including OPEN Alliance EMC Spec 2.0

  • Designed according to ISO26262, it meets ASIL-A to ease the design of safe vehicles
  • Being designed and fully qualified for automotive applications, the TJA1101B offers 100Mbit/s transmit and receive capability over up to at least 15m of unshielded twisted pair (UTP) cable
  • The highly integrated device is robust by design, saving external filter and ESD protection components in the MDI path
  • Future proof by enabling fully OPEN Alliance TC-10 compliant sleep and wakeup forwarding over the data line, it saves wire cost and weight by replacing dedicated wake-up lines

Block Diagram

TJA1101B

TJA1101B Block Diagram
Get diagram PDF

Features

Automotive Qualified

  • AEC-Q100 Grade 1
  • Ambient Temperature -40°C to 125°C

IEEE 100BASE-T1 Compliant PHY Transceiver

  • Interoperable with any IEEE 100BASE-T1 and OABR compliant PHY
  • 100Mbps Ethernet over single unshielded twisted pair (UTP) cable
  • ESD robust MDI:
    • Passes IEC62228-5 Class IV
    • Protected against +/- 8kV according to IEC61000-4-2

OPEN Alliance TC-10 Compliant Sleep / Wake Up

  • Sleep and wake-up forwarding over data line
  • For reduced cable cost and weight
  • With direct connection to Vbat for simplified power management

ISO26262 ASIL-A

  • Safety manual available to support system level safety goals

Optimized for Automotive Use Cases

  • MDI pins do not need an external filter or ESD protection
  • Cable polarity detection and auto-correction
  • Supports single 3.3V supply
  • Direct connection to Vbat

Advanced Diagnostic Features

  • Real-time Signal Quality Indicator
  • Gap Free Under Voltage Detection
  • Diagnosis of Cabling Errors

HVQFN36 (6mm x 6mm) with Wettable Flanks

  • Small PCB footprint enabled for AOI

More
