Automotive Math and Motor Control Library (AMMCLib)

AMMCLIB

Roll over image to zoom in

The Automotive Math and Motor Control Library (AMMCLib) set provides essential building blocks for rapid development of automotive embedded applications with high-performance arithmetic, trigonometric, digital signal processing and math functions. The AMMCLib is available as a production-ready precompiled or source code package.

A significant portion of the AMMCLib supports both sensor-based and sensorless motor control applications; it also assists with fixed-point fractional 16/32-bit and single-precision floating-point arithmetic. All AMMCLib functions come with MATLAB® and Simulink® bit-accurate models for model-based design, simulation and code generation supporting Embedded Coder®.

Diagram

Choose a diagram:

Auto AMMCLIB General Architecture­

General Architecture

Auto AMMCLIB Architecture for KEA

Architecture for KEA

Auto AMMCLIB Architecture for S32Z/E and S32V

Architecture for S32S and S32V234

Automotive software General Block Diagram

Automotive General Block Diagram
Get diagram PDF

Features

  • Developed according to SPICE Level 3, ISO/TS 16949:2009, in conjunction with ISO 9001:2008 processes. Also compliant with ISO/IEC 9899:1999
  • Common interface across all platforms for easy migration and CPU-specific internal optimizations for maximum performance: takes advantage of SIMD extensions: SPE, LSP, Arm® Neon, Arm DSP for Cortex®-M
  • Long-term support of new and old MCUs: new features regularly released for all supported platforms
  • MATLAB and Simulink models for design, simulation and code generation
  • Supports NXP S32 Design Studio (S32DS), NXP CodeWarrior®, Green Hills MULTI, Wind River Diab, IAR for Arm and Cosmic® compilers (supported compilers may vary based on the device)
  • AMMCLib comprehensive hierarchy:
    • Saturated arithmetic and bitwise functions (MLIB) with basic low-level inline functions
    • General trigonometric and controller functions (GFLIB) with a fast trigonometric, look-up table, limitations, hysteresis, logarithm and controller functions
    • General motor control functions (GMCLIB) with space vector modulation, transformations and other dedicated motor control functions
    • General digital filters functions (GDFLIB) with FIR, IIR and EWMA digital filters
    • Advanced motor control functions (AMCLIB) with FOC macroblocks, BEMF observers for sensorless applications, on-the-fly startup and robust PMSM field weakening controller
    • Advanced digital filters functions (ADFLIB) with sensor processing and fusion, advanced simulation for calibration, fast Fourier transform (FFT) and general matrix/vector functions available for Arm Cortex-A53 and R52 based MCUs

Supported Devices

Downloads

Quick reference to our software types.
Filters

1-5 of 24 downloads

  • Libraries

    Automotive Math and Motor Control Library Set for S32Z and S32Eupdated

    FLEXERARev 1.1.42Oct 21, 2025 00:00:001 KBSW32ZSE-MMCL1D
    Download
  • Libraries

    Automotive Math and Motor Control Library Set for MPC560xP

    FLEXERARev 1.1.39Dec 20, 2024 00:00:001 KBSW560XP-MMCL1D
    Download
  • Libraries

    Automotive Math and Motor Control Library Set for MPC5775E

    FLEXERARev 1.1.39Dec 20, 2024 00:00:001 KBSW5775E-MMCL1D
    Download
  • Libraries

    Automotive Math and Motor Control Library Set for S32M24Xupdated

    FLEXERARev 1.1.42Oct 21, 2025 00:00:001 KBSW32M24X-MMCL1D
    Download
  • Libraries

    Automotive Math and Motor Control Library Set for Kinetis KEAupdated

    FLEXERARev 1.1.42Oct 21, 2025 00:00:001 KBSWKEA-MMCL1D
    Download
Show All
