Power Management IC (PMIC) for i.MX 8M Mini/Nano/Plus

PCA9450 Active

Roll over image to zoom in

The PCA9450 is a single chip power management IC (PMIC) specifically designed to support i.MX 8M family processor in both 1 cell Li-Ion and Li-polymer battery portable application and 5 V adapter nonportable applications.

The device provides six high-efficiency step-down regulators, five LDOs, one 400 mA load switch, 2 channel level translator and 32.768 kHz crystal oscillator driver. Three buck regulators support dynamic voltage scaling (DVS) feature along with programmable ramping up and down time and those buck regulators support remote sense to compensate IR drop to load. This device is characterized across -40 °C to 105 °C ambient temperature range.

Features

High-Efficiency Step Down Regulators

  • Three 3 A buck regulators with DVS feature and remote sense
  • PCA9450A - Three 3 A buck regulators
  • PCA9450B - Two 3 A buck regulators
  • PCA9450C - Dual-phase configurable 6 A buck regulator
  • One 3 A buck regulator
  • Two 2 A buck regulators

Linear Regulators

  • Two 10 mA LDO
  • One 150 mA LDO
  • One 200 mA LDO
  • One 300 mA LDO

General Features

  • 400 mA load switch with active discharge
  • 32.768 kHz crystal oscillator buffer output
  • Level translator
  • Fm+ 1 MHz I²C interface
  • Output current 3 A, 6 A
  • i.MX 8M Mini, i.MX 8MNano, i.MX 8M Nano and i.MX 8M Plus MCU supported
  • I²C interface and input control

Power Control IO

  • Power ON/OFF control
  • Standby / Run mode control

ESD Protection

  • Human body model (HBM) : +/- 2000 V
  • Charged device model (CDM) : +/-500 V

Package

  • 7 mm x 7 mm, 56-pin HVQFN with 0.4 mm pitch
