PF8200/PF8100 Programming Board

KITPF8200FRDMPGM Active

Roll over image to zoom in

The KITPF8200FRDMPGM is a programming board featuring a 56 pin QFN socket compatible with all PF81xx and PF82xx PMICs. It integrates a communication bridge based on the FRDM-KL25Z freedom board to communicate with the FlexGUI software interface to program the OTP configuration.

Block Diagram

Choose a diagram:

KITPF8200FRDMPGM Block Diagram

PF8100/PF8200 Multi-channel PMIC Block Diagram

KITPF8200FRDMPGM Block Diagram 2

PF8101/PF8201, 9-channel PMIC Block Diagram

KITPF8200FRDMPGM Block Diagram 3

PF8121, 12-channel PMIC Block Diagram
Get diagram PDF

Supported Devices

Power Management

PMICs

  • PF81-PF82: 12-Channel Power Management Integrated Circuit (PMIC) for High-Performance Processing Applications
  • PF8101-PF8201: 9-Channel Power Management Integrated Circuit (PMIC) for High-Performance Processing Applications
  • PF8121: 12-Channel Power Management Integrated Circuit (PMIC) for High-Performance Consumer Applications

Features

Programming Socket

  • Clamshell 56-pin QFN socket

System Features

  • 5.0 V operating input voltage range (from USB connector)
  • Integrated boost converted to supply VDDOTP programming voltage
  • USB to I²C communication via the FRDM-KL25Z interface
  • In-line programming interface connector

Buy Options

KITPF8200FRDMPGM-Image

Click to expand

  • KITPF8200FRDMPGM
    Active

  • PF8200/PF8100 Programming Board.

    • Assembled and tested KITPF8200FRDMPGM and preprogrammed FRDM-KL25Z MCU board in an anti-static bag
    • 3.0ft. USB-STD A to USB-B-mini cable
    • USB to mini USB cable
    • Quick Start Guide
  • $193.20 USD
  • For a quantity of 1
    • Availability: In Stock
    • Inventory: 1
    • Shipping: Normally ships 1-2 business days
ADD TO CART
Order from distributors
