Freedom Development Board for Kinetis® KW0x

FRDM-KW019032 Preproduction

Roll over image to zoom in

Note: this page is made available for historical reference only.

The NXP® FRDM-KW019032 is a development platform based on the Our MKW01Z128CHN Kinetis® W Series microcontroller, and is enabled by software support for 802.15.4 MAC/PHY, SMAC and Kinetis Software Development Kit (SDK). The FRDM-KW019032 kit contains two boards, enabling point-to-point out of the box connectivity.

Powered by the ultra-low-power 48 MHz Arm® Cortex®-M0+ 32-bit core, the Kinetis KW0x family of MCUs embeds a rich set of peripherals such as a high-performance, bi-directional sub-1 GHz radio capable of operating over a wide frequency range of 315, 433, 470, 868, 915, 928 and 960 MHz in the license-free industrial, scientific and medical frequency bands.

FRDM-KW019032 evaluation boards are designed to work either in standalone mode or as part of the Freedom development platforms for quick application prototyping. They are fully supported by a comprehensive enablement environment.

Product Details

Supported Devices

Wireless Connectivity

Sub-GHz ISM Bands

  • KW0x: Kinetis® KW0x-48 MHz, Sub-1 GHz Wireless Radio Microcontrollers (MCUs) based on Arm® Cortex®-M0+ Core

Features

Processor

  • 32-bit Arm® Cortex®-M0+ 48 MHz Core

Memory

  • Programmable 128 kB Flash and 16 kB SRAM

Connectivity

  • Integrated chip antenna for RFIO port, and footprint for SMA RFIO and PA_BOOST ports

Power Management

  • Programmable output power from –18 dBm to +17 dBm in 1 dB steps
  • High sensitivity: down to –120 dBm at 1.2 kbit/s

Debug

  • Integrated open-standard serial and debug interface (OpenSDAv2.1)

Support

  • Full KSDK support
  • Software/Protocol Stacks
    • IEEE 802.15.4
    • NXP® Simple MAC (SMAC)
  • LEDs and switches for demonstration, monitoring, and control
  • Compliant FCC Part15 and IC RSS 210
  • Minimum number of matching components
  • Programmable FSK, GFSK, MSK, GMSK, and OOK modulations
  • Packet engine with CRC, AES-128 encryption, and 66-byte FIFO
