i.MX RT1064 Crossover MCUs are based on the Arm® Cortex®-M7 core forreal-time microcontroller (MCU) performance and high integration for industrial and IoT applications.
The i.MX RT1064 Arm® Cortex®-M7 operates at up to 600 MHz with 4 MB on-chip flash and 1 MB on-chip RAM. The family offers 2D graphics, camera, various memory interfaces, a wide range of connectivity interfaces including UART, SPI, I²C, USB, 2x 10/100M Ethernet and 3x CAN. Additional features for real-time applications include high-speed GPIO, CAN-FD and synchronous parallel NAND/NOR/PSRAM controller.
The i.MX RT1064 family is supported by the MCUXpresso ecosystem, which includes an SDK, a choice of IDEs and secure provisioning and configuration tools to enable rapid development.
Are you working with NXP processors or microcontrollers?
Don’t spend your money solving issues that NXP has already solved.
With NXP’s Premium Support, you’re getting expert help and a contractually obligated agreement for high-quality technical assistance. Enjoy guaranteed response times and direct access to NXP engineers who have likely already solved the issues you are facing.
Benefits include:Click here to discover how Premium Support can optimize your next design.
i.MX RT1040 Crossover MCU with Arm® Cortex®-M7 Core Operating Up to 600 MHz and Extended Temperature Range
2.4/5 GHz Dual-Band 1x1 Wi-Fi® 6 (802.11ax) + Bluetooth® 5.4 + 802.15.4 Tri-Radio Solution
i.MX RT1050 Crossover MCU with Arm® Cortex®-M7 Core
i.MX RT1060: Crossover MCU with Arm® Cortex®-M7
4 results
Include 4 NRND
Part | Order | CAD Model | Status | Core: Number of cores (SPEC) | Core Type | Operating Frequency [Max] (MHz) | Flash (kB) | SRAM (kB) | CAN | I2C | UART | USB Controllers | Junction Temperature (Min to Max) (℃) | Debug & Trace | Package Type | Package Pitch (mm) |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Active | 1 | Arm Cortex-M7 | 528 | 4000 | 1024 | 2 | 4 | 8 | 2 | -40 to 105 | JTAG | LFBGA196 | 0.8 | |||
Active | 1 | Arm Cortex-M7 | 528 | 4000 | 1024 | 2 | 4 | 8 | 2 | -40 to 105 | JTAG | LFBGA196 | 0.65 | |||
Active | 1 | Arm Cortex-M7 | 600 | 4000 | 1024 | 2 | 4 | 8 | 2 | 0 to 95 | JTAG | LFBGA196 | 0.8 | |||
Active | 1 | Arm Cortex-M7 | 600 | 4000 | 1024 | 2 | 4 | 8 | 2 | 0 to 95 | JTAG | LFBGA196 | 0.65 |
