MC56F84xxx Active

The MC56F84xxx is based on our 32-bit DSP core.

A high speed digital signal controller, offering exceptional precision, sensing and control for a very efficient digital power conversion and advanced motor control applications.

The MC56F84xxx includes advanced high-speed and high-accuracy peripherals.

Block Diagram

MC56F84XX Block Diagram

MC56F84XX Digital Signal Controllers Block Diagram
Get diagram PDF

Features

  • 100 MHz/100 MIPS 32-bit DSP core
  • 64 KB to 256 KB flash memory flexibility and Direct Memory Access (DMA) controller
  • Single-cycle math computations, fractional arithmetic support and parallel moves
  • Up to 24 PWM channels with input capture
  • Hi-res PWMs with 312 pico-second resolution
  • 2x 12-bit high-speed (HS) ADCs with 3.3 Msps resolution
  • 1x 16-bit ADC with 1 Msps resolution
  • 4 analog comparators with integrated 6-bit DACs speed system event identification and shutdown of the PWM outputs
  • 1 12-bit DAC with auto waveform generation
  • Various communication peripherals: 3 QSCIs; 3 QSPIs; 2 I²C/SMBus; 1 FlexCAN
  • This product is included in our product longevity program, with assured supply for a minimum of 15 years after launch
