2.4/5 GHz Dual-Band 2x2 Wi-Fi® 6 (802.11ax) + Bluetooth® 5.3 Automotive Solution

88Q9098

Roll over image to zoom in

The 88Q9098 family of automotive wireless SoCs is the industry’s first Wi-Fi 6 solution based on the latest IEEE 802.11ax standards supporting 2x2 plus 2x2 concurrent dual Wi-Fi and dual-mode Bluetooth 5.3. Delivering reliable and high-performance wireless connectivity is becoming more difficult in the increasingly congested automobile environment. The new 88Q9098 combo solution enables gigabit-level performance, superior reliability, and enhanced security for the car and extends leadership in providing comprehensive Wi-Fi 6 solutions. Our innovative concurrent dual Wi-Fi architecture sets a new technology precedent, integrating two complete Wi-Fi subsystems into a single SoC, and enabling two independent 2x2 data streams to run concurrently and at full throughput.

The 88Q9098 family of footprint compatible wireless solutions include:

  • 88Q9098 - 2x2 + 2x2 Concurrent Dual Wi-Fi with Bluetooth 5 (AEC-Q100 grade 3)
  • 88Q9098S - 2x2 + 2x2 Concurrent Dual Wi-Fi with Bluetooth 5 (AEC-Q100 grade 2)

Wireless modules based on the NXP 88Q9098 are offered by leading module manufacturers.

Block Diagram

Choose a diagram:

88Q9098 SoC Application Block Diagram (Internal PA/LNA/SW)

88Q9098 Block Diagram Interior App

88Q9098 SoC Internal Block Diagram

88Q9098 SoC Internal Block Diagram
Get diagram PDF

Features

Concurrent Dual 2x2 Wi-Fi Operation

  • IEEE 802.11ax / IEEE 802.11ac
  • 20/40/80 MHz channel bandwidths
  • Zero Wait DFS
  • Implicit and explicit beamforming

Wi-Fi 6

  • Downlink OFDMA and MU-MIMO
  • Uplink OFDMA and MU-MIMO
  • 1024 QAM
  • Target Wake Time

Bluetooth

  • Bluetooth Class 1.5 and Class 2
  • Bluetooth Low Energy (LE) 1 Mbit/s and 2 Mbit/s
  • Bluetooth Low Energy Long Range

AEC-Q100 support

  • Grade 2 (-40C to +105C)
  • Grade 3 (-40C to +85C)

Host Interface (Wi-Fi + Bluetooth)

  • PCIe 2.0 + UART
  • SDIO 3.0 + SDIO 3.0
  • SDIO 3.0 + UART
