P3T1755DP is a ±0.5°C accurate temperature-to-digital converter with a -40 °C to +125 °C range. It uses an on-chip band gap temperature sensor and A-to-D conversion technique with overtemperature detection. The temperature register always stores a 12 bit two's complement data, giving a temperature resolution of 0.0625 °C P3T1755DP which can be configured for different operation conditions: continues conversion, one-shot mode or shutdown mode.
The device supports 2-wire serial I3C (up to 12.5 MHz) and I²C (up to 3.4 MHz) as communication interface. In I²C, the device supports up to four target addresses and an alert function. In I3C, the devices support in-band interrupt (IBI), where the same bus is used to report the alert interrupts.
Participating products are available for a minimum of 10 years. Designated participating products developed for the automotive, telecom and medical segments are available for a minimum of 15 years.
2 results
Include 0 NRND
Part | Order | CAD Model | Status | Accuracy on-chip (±°C) | Supply Voltage [Min to Max] (V) | Communication protocol | # of Addresses | Resolution (°C) | Package Type | Package Dimensions (LxWxZ (mm)) | Operating Temperature (Min-Max) (℃) | AEC-Q100 compliant | Budgetary Price excluding tax |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Active | 0.5 | 1.4 to 3.6 | I3C, I²C | 32 | 0.06 | TSSOP8 | 3 x 3 x 1.1 | -40 to 125 | N | 1K @ US$0.20 | |||
Active | 0.5 | 1.4 to 3.6 | I3C, I²C | 27 | 0.06 | TSSOP8 | 3 x 3 x 1.1 | -40 to 125 | Y | 1K @ US$0.30 |
