2.4/5 GHz Dual-Band 4x4 Wi-Fi® 6 (802.11ax) Access Solution

  • This page contains information on a product that is not recommended for new designs.

Product Details

Block Diagram

88W9064 Block Diagram

88W9064 Block Diagram

Features

Wi-Fi 6

  • Downlink OFDMA and MU-MIMO
  • Uplink OFDMA and MU-MIMO
  • 1024 QAM
  • Spatial reuse
  • Range extension
  • DCM
  • Target Wake Time

Flex MAC

  • Adaptable architecture for standards evolution
  • Management of high number of traffic queues
  • Advanced scheduling

Bluetooth

  • Support for Bluetooth 5
  • Direction finding
  • Long range
  • Coexistence arbitration

Dedicated In-Service Monitoring

  • Concurrent spectrum scanning
  • Zero wait DFS

Precision Location

  • Distance: within 1 meter
  • Angle: within 10 degrees

Host Interfaces

  • PCIe 3.0 (2-Lane)
  • High-Speed UART (for Bluetooth)
