The TJA1057 is part of the Mantis family of high-speed CAN transceivers. It provides an interface between a controller area network (CAN) protocol controller and the physical two-wire CAN bus. The transceiver is designed for high-speed CAN applications in the automotive industry, providing the differential transmit and receive capability to (a microcontroller with) a CAN protocol controller.
The TJA1057 offers a feature set optimized for 12 V automotive applications, with significant improvements over first- and second-generation CAN transceivers from NXP, such as the TJA1050, and excellent electro magnetic compatibility (EMC) performance.
The TJA1057 also displays ideal passive behavior to the CAN bus when the supply voltage is off.
Participating products are available for a minimum of 10 years. Designated participating products developed for the automotive, telecom and medical segments are available for a minimum of 15 years.
High-Speed CAN Transceiver with Standby Mode - Mantis Family
5 results
Include 2 NRND
Part | Order | CAD Model | Status | Recommended Orderable Part Number | MCU I/O Interface (V) | VIO Option Available | Low Power Modes | Data Rate [max] kbps | Package Type | CAN Channels | Product Category | Supply Voltage [Min to Max] (V) | Data Rate [min] kbps | Voltage on bus pins [Min-Max] (V) | VESD IEC on bus pins (+/- kV) | VESD HBM on bus pins (+/- kV) | Junction Temperature (Max) (℃) | Protection | Wake-Up Pin | Min High Input Levels (V) [Vio] | GPIO | Supported standards | SPLIT Pin | Thermal Resistance (Spec) (℃/W) | Product Application |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Active | TJA1057BT/0Z | 3.3, 5.0 | N | Silent mode | 5000.0 | SO8 | 1 | CAN FD / High-Speed CAN | 4.5 to 5.5 | 40.0 | -42 to 42 | -8 to 8 | -8 to 8 | 150 | TXD dominant timeout, overtemperature detection, undervoltage detection | N | 2 | 8 | ISO-11898-2:2016, SAE J2284-1, SAE J2284-2, SAE J2284-3, SAE J2284-4, SAE J2284-5 | N | 97 | Automotive, Industrial | |||
Active | TJA1057BTK/0J | 3.3, 5.0 | Y | Silent mode | 5000.0 | HVSON8 | 1 | CAN FD / High-Speed CAN | 4.5 to 5.5 | 40.0 | -42 to 42 | 0 to 0 | 0 to 0 | 150 | TXD dominant timeout, overtemperature detection, undervoltage detection | N | 2 | 8 | ISO-11898-2:2016, SAE J2284-1, SAE J2284-2, SAE J2284-3, SAE J2284-4, SAE J2284-5 | N | 97 | Automotive, Industrial | |||
Active | TJA1057BT/0Z | 3.3, 5.0 | N | Silent mode | 5000.0 | SO8 | 1 | CAN FD / High-Speed CAN | 4.5 to 5.5 | 40.0 | -42 to 42 | -8 to 8 | -8 to 8 | 150 | TXD dominant timeout, overtemperature detection, undervoltage detection | N | 2 | 8 | ISO-11898-2:2016, SAE J2284-1, SAE J2284-2, SAE J2284-3, SAE J2284-4, SAE J2284-5 | N | 97 | Automotive, Industrial | |||
Active | TJA1057CTK/0J | 5.0 | N | Silent mode | 5000.0 | HVSON8 | 1 | CAN FD / High-Speed CAN | 4.5 to 5.5 | 40.0 | -42 to 42 | 0 to 0 | 0 to 0 | 150 | TXD dominant timeout, overtemperature detection, undervoltage detection | N | 2 | 8 | ISO-11898-2:2016, SAE J2284-1, SAE J2284-2, SAE J2284-3, SAE J2284-4, SAE J2284-5 | N | 97 | Automotive, Industrial | |||
Active | TJA1057GTK/3Z, TJA1057GTKZ | 3.3, 5.0 | N | Silent mode | 5000.0 | HVSON8 | 1 | CAN FD / High-Speed CAN | 4.5 to 5.5 | 40.0 | -42 to 42 | -8 to 8 | -8 to 8 | 150 | TXD dominant timeout, overtemperature detection, undervoltage detection | N | 2 | 8 | ISO-11898-2:2016, SAE J1939-14, SAE J2284-1, SAE J2284-2, SAE J2284-3, SAE J2284-4, SAE J2284-5 | N | 145 | Automotive, Industrial |
