PCAL6416A 16-bit GPIO Arduino® Shield Evaluation Board

PCAL6416AEV-ARD

Roll over image to zoom in

The PCAL6416AEV-ARD Arduino Shield allows easy integration with Arduino EVKs to evaluate 16-bit general-purpose I/O expander features for interfacing to sensors, push buttons, keypad, etc. A graphical interface allows the user to easily explore the different functions of the GPIO expander to create an evaluation system.

Supported Devices

Interfaces

General Purpose I/O (GPIO)

  • PCAL6416A: Low-Voltage Translating 16-Bit I²C-Bus/SMBus I/O Expander

Features

General Features

  • I/O connector for external access to IC input-output pins
  • Eight user switches connected to I/O pins of the IC
  • Eight user LEDs connected to I/O pins of the IC
  • Equipped with Arduino Uno R3 port for direct connection with Arduino devices
  • Fully compliant with IMXRT1050 EVK board
  • Fully compliant with LPCXpresso55S69 dev. board
  • Compliant with i.MX Mini LPDDR4 EVK board

Buy Options

PCAL6416AEV-ARD-Image

Click to expand

  • PCAL6416AEV-ARD

  • PCAL6416A 16-bit GPIO Arduino® Shield Evaluation Board.

  • Kit contains:

    • PCAL6416AEV-ARD Arduino Shield
    • Quick Reference Card
    • Additional hardware required: USB A-to-MicroB cable (not included)
  • $33.33 USD
  • For a quantity of 1
    • Availability: In Stock
    • Inventory: 20
    • Shipping: Normally ships 1-2 business days
ADD TO CART
