PCA9617ADP-ARD Arduino® Shield Level Translating Fm+ I²C-Bus Repeater Evaluation Board

PCA9617ADP-ARD

Roll over image to zoom in

The PCA9617ADP-ARD evaluation board is a expansion board equipped with an Arduino port, designated for easy testing and design of PCA9617A IC, level translating FM+ I²C-bus repeater. The board is fully compliant with IMXRT1050 EVK, LPCXpresso55S69 (LPC55S69-EVK) and i.MX 8M Mini LPDDR4 EVK (8MMINILPD4-EVK, 8MMINID4-EVK), including GUI software control. The board can be attached to any device equipped with an Arduino port.

Product Details

Supported Devices

Interfaces

I²C-Bus Repeaters/Hubs/Extenders

  • PCA9617A: Level Translating Fm+ I²C-Bus Repeater

Features

General Functions

  • Voltage level translating
  • I²C-bus repeater
  • FM+
  • Bidirectional buffer isolates capacitance

Power

  • Supply voltage: Vcc(A) 0.8V to 5.5V, Vcc(B) 2.2V to 5.5V
  • Icc(A): 50 uA(max)

Voltage Translation

  • Allows bidirectional voltage-level translation and I²C-bus repeater:
    • 1.8 V SCLA/SDAA and 1.8 V, 2.5 V, 3.3 V or 5 V SCLB/SDAB
    • 2.5 V SCLA/SDAA and 1.8 V, 2.5 V, 3.3 V or 5 V SCLB/SDAB
    • 3.3 V SCLA/SDAA and 1.8 V, 2.5 V, 3.3 V or 5 V SCLB/SDAB
    • 5 V SCLA/SDAA and 1.8 V, 2.5 V, 3.3 V or 5 V SCLB/SDAB

Interface

  • FM+, 1MHz I²C bus
  • EN pin

Package

  • TSSOP8, HWSON8

Buy Options

PCA9617ADP-ARD-Image

Click to expand

  • PCA9617ADP-ARD

  • PCA9617ADP-ARD Arduino® Shield Level Translating Fm+ I²C-Bus Repeater Evaluation Board.

  • Kit contains:

    • Assembled and tested evaluation board in an antistatic bag
    • Quick Start Guide
  • $22.22 USD
  • For a quantity of 1
    • Availability: In Stock
    • Inventory: 10
    • Shipping: Normally ships 1-2 business days
