AUTOSAR® 4.0.x (Classic Platform) Software

AUTOSAR-4

Roll over image to zoom in

AUTOSAR (Classic Platform) 4.0 is the first version supporting Ethernet in all layers of the communication stack. Also includes diagnostic log and trace capability (in the system services layer), updated configuration schemata for system level, ECU level, and module level configuration descriptions. AUTOSAR (Classic Platform) 4.0 targets automotive and industrial, except for ultra-hazardous applications.

AUTOSAR (Classic Platform) 4.0 is the second NXP-supported major version with improved and matured standard specifications —compared to version 3.0. Therefore, AUTOSAR 4.0 and AUTOSAR 3.0 software cannot easily be used in a mixed way.

The AUTOSAR OS can still be configured to scalability class 1 (backwards compatible to OSEK).

Diagram

AUTOSAR 4.0

AUTOSAR 4.0
Get diagram PDF

Features

General features

  • Compliant to AUTOSAR Release 4.0 rev 3
  • User and integration manual, module configuration, module generation
  • Source code for all included MCAL modules
  • Development Process following Automotive SPICE Level 3, QM
  • Tested with multiple 3rd party compilers (specified in the release notes of each package)
  • Includes 3rd party AUTOSAR configuration tool (EB tresos Studio)
  • Compliant to AUTOSAR Release 4.0 rev 3
  • Scalability class 1 (other scalability classes may be supported depending on OS package)
  • User and integration manual, module configuration, module generation
  • Source code for the OS
  • Development Process following Automotive SPICE Level 3, QM
  • Tested with multiple 3rd party compilers (specified in the release notes of each package)
  • Includes 3rd party AUTOSAR configuration tool (EB tresos Studio)

AUTOSAR Modules

  • Microcontroller Drivers: MCU, WDG, GPT
  • I/O Drivers: DIO, PORT, PWM, ICU, ADC
  • Memory drivers: FLS, FEE
  • Communication drivers: CAN, LIN, SPI, FR (FR not in every package)

Supported Devices

  • MPC574xP: Ultra-Reliable MPC574xP MCU for Automotive and Industrial Safety Applications
  • MPC5746R: Automotive and Industrial Engine Management MCU
  • MPC574xB-C-G: Ultra-Reliable MPC574xB/C/G MCUs for Automotive and Industrial Control and Gateway
  • MPC5676R: Ultra-Reliable MPC5676R MCU for Automotive and Industrial Engine Management
  • MPC564xL: Ultra-Reliable Dual-Core 32-bit MCU for Automotive and Industrial Applications
  • MPC577xK: Ultra-Reliable MPC577xK MCU for ADAS and Radar
  • MPC560xP: Ultra-Reliable MPC560xP MCU for Automotive and Industrial Safety Applications
  • S12ZVM: S12ZVM Mixed-Signal MCU for Automotive and Industrial Motor Control Applications
  • MPC5777M: Ultra-Reliable MPC5777M MCU for Automotive and Industrial Engine Management
  • MPC564xB-C: Ultra-Reliable MPC564xB-C MCU for Automotive and Industrial Control Applications
  • MPC567xK: Ultra-Reliable MPC567xK MCU for Automotive and Industrial Radar Applications
  • MPC564xA: Ultra-Reliable MPC564xA MCU for Automotive and Industrial Engine Management
  • MPC560xB: Ultra-Reliable MPC56xB MCU for Automotive and Industrial General Purpose
  • S12ZVC: S12ZVC Mixed-Signal MCU for Automotive and Industrial CAN Applications

Downloads

Quick reference to our software types.
Filters

1-5 of 28 downloads

  • OS and RTOS

    AUTOSAR 4.0 OS for S12Z

    EXERev 0May 21, 20191 KBSWS12Z-OS401E
    Download
  • BSPs and Device Drivers

    AUTOSAR 4.0 MCAL (QM) for MAC57D5x (M4)

    EXERev 1.0.xFeb 21, 20191 KBSWAC57D-MCAL401E
    Download
  • BSPs and Device Drivers

    AUTOSAR 4.0 MCAL (QM) for S12ZVC

    EXERev 1.0.xFeb 21, 20191 KBSWS12Z-MCAL401E
    Download
  • BSPs and Device Drivers

    AUTOSAR 4.0 MCAL (QM) for S12ZVMC256

    FLEXERARev 10.xApr 20, 20181 KBSWS12ZVC-MCAL401E
    Download
  • BSPs and Device Drivers

    AUTOSAR 4.0 MCAL (ISO 26262) for S32K118 and S32K14x

    FLEXERARev 1.0.xFeb 6, 20181 KBSW32K14-SMCL401E
    Download
Show All

Note: For better experience, software downloads are recommended on desktop.
