SD6 Programmable Driver for Solenoid Control

MC33816 Active

Roll over image to zoom in

The NXP MC33816 is a programmable gate driver IC for precision solenoid control applications.

  • The IC consists of five external MOSFET high-side pre-drivers and seven external MOSFET low-side pre-drivers
  • Provides a flexible solution for MOSFET gate drive with a versatile control and optimized latency time
  • Gate drive, diagnosis, and protection are managed through four independent microcores, two code RAM and two data RAM banks
  • The IC contains two internal voltage regulators

View internal diagram

Block Diagram

MC33816 System

MC33816 System Diagram
Get diagram PDF

Features

Key Features

  • Battery voltage range, 5.0 V < VBATT < 32 V
  • Pre-drive operating voltage up to 72 V
  • High-side/ low-side pre-drive PWM capability up to 100 KHz (30 nCoulomb)
  • All pre-drivers have four selectable slew rates
  • Eight selectable, pre-defined VDS monitoring thresholds
  • Encryption for microcode protection

Buy/Parametrics

2 results

Include 0 NRND

Part

Show description

Order

CAD Model

Status

Device Function

End of Injection Detection

Package Type

Package Termination Count

Budgetary Price excluding tax

Frequency (Max) (kHz)

Number of Channels

Protection

Supply Voltage [min] (V)

Supply Voltage [max] (V)

SPI [bits]

Number of High Side Pre Driver

Number Low Side Pre Driver

Ambient Operating Temperature (Min to Max) (℃)

MC33816AE
Data Sheet

Active

powertrain control, pre-driver

N

HLQFP64

64

1K @ US$4.00

200

4

drain to source voltage/voltage source, open load, overcurrent, overtemperature, overvoltage protect, short-circuit, undervoltage, undervoltage lockout

5

72

16

5

7

-40 to 125

MC33816MAE
Data Sheet

Active

—

—

HLQFP64

64

1K @ US$4.30

—

—

—

—

—

—

—

—

—

N true 0 PSPMC33816en 10 Application Note Application Note t789 3 Application Note Software Application Note Software t783 1 Data Sheet Data Sheet t520 1 Errata Errata t522 1 Fact Sheet Fact Sheet t523 1 User Guide User Guide t792 3 en_US 1 1 10.0 English The 33816 is a SMARTMOS programmable gate driver IC for precision solenoid control applications. 1353093661081728217618 PSP 4.4 MB None None documents None 1353093661081728217618 /docs/en/data-sheet/MC33816.pdf 4408774 /docs/en/data-sheet/MC33816.pdf MC33816 N N 2016-10-31 MC33816, SD6 programmable solenoid controller for precision solenoid control applications - Data Sheet /docs/en/data-sheet/MC33816.pdf /docs/en/data-sheet/MC33816.pdf Data Sheet N Y 980000996212993340 2023-08-18 pdf N en Feb 15, 2023 Data Sheet t520 Data Sheet Data Sheet Y N MC33816, SD6 programmable solenoid controller for precision solenoid control applications - Data Sheet false en_US en Application Note Application Note 3 2 5 English AN4849SW.zip /docs/en/application-note-software/AN4849SW.zip /docs/en/application-note-software/AN4849SW.zip Example of a four cylinder internal combustion engine (ICE) injector drive. 1389907360154740727519 PSP 369.9 KB Registration without Disclaimer None documents Extended 1389907360154740727519 /secured/assets/documents/en/application-note/AN4849.pdf 369909 /secured/assets/documents/en/application-note/AN4849.pdf AN4849 documents Y N 2016-10-31 AN4849, Four injector and fuel pump drive - Application Note /webapp/Download?colCode=AN4849 /secured/assets/documents/en/application-note/AN4849.pdf Application Note N 645036621402383989 2022-12-07 pdf Y en Jul 15, 2019 645036621402383989 Application Note Y N AN4849, Four injector and fuel pump drive - Application Note 3 3.0 English AN4954SW.zip /docs/en/application-note-software/AN4954SW.zip /docs/en/application-note-software/AN4954SW.zip This application note explains how to use MC33816 diagnostics in a typical four cylinder internal combustion engine (ICE) application. 1403195137764713068708 PSP 1.1 MB None None documents None 1403195137764713068708 /docs/en/application-note/AN4954.pdf 1109976 /docs/en/application-note/AN4954.pdf AN4954 documents N N 2014-06-19 AN4954, MC33816 Diagnostics - Application Note /docs/en/application-note/AN4954.pdf /docs/en/application-note/AN4954.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Feb 3, 2016 645036621402383989 Application Note Y N AN4954, MC33816 Diagnostics - Application Note 4 1.0 English MC33816 and PT2000 are programmable solenoid controllers used to drive external N Channel MOSFETs, and are mainly used to drive direct fuel injectors and valves. 1444929321147694232840 PSP 323.0 KB None None documents None 1444929321147694232840 /docs/en/application-note/AN5203.pdf 323027 /docs/en/application-note/AN5203.pdf AN5203 documents N N 2015-10-15 AN5203, MC33816 vs. PT2000 - Application Note /docs/en/application-note/AN5203.pdf /docs/en/application-note/AN5203.pdf Application Note N 645036621402383989 2022-12-07 pdf N en Nov 18, 2015 645036621402383989 Application Note Y N AN5203, MC33816 vs. PT2000 - Application Note User Guide User Guide 3 5 2.0 English The PT2000 and MC33816 Developer Studio (IDE) software, and the KITPSCDEBUGEVM are used to configure, receive, and decode the trace codes coming from the device under test. 1447957687765700483033 PSP 3.2 MB None None documents None 1447957687765700483033 /docs/en/user-guide/KTPSCDEBUGUG.pdf 3155664 /docs/en/user-guide/KTPSCDEBUGUG.pdf KTPSCDEBUGUG documents N N 2015-11-19 KTPSCDEBUGUG, KITPSCDEBUG Evaluation Board - User&#8217;s Guide /docs/en/user-guide/KTPSCDEBUGUG.pdf /docs/en/user-guide/KTPSCDEBUGUG.pdf User Guide N 132339537837198660 2022-12-07 pdf N en Nov 16, 2015 132339537837198660 User Guide Y N KTPSCDEBUGUG, KITPSCDEBUG Evaluation Board - User&#8217;s Guide 6 2.0 English MC33816 Developer Studio is a Windows application created to streamline the development of micro code for the MC33816 Programmable Solenoid Controller. 1421361662470732669197 PSP 2.0 MB None None documents None 1421361662470732669197 /docs/en/user-guide/MC33816DSWUG.pdf 2020372 /docs/en/user-guide/MC33816DSWUG.pdf MC33816DSWUG documents N N 2015-01-15 MC33816DSWUG, MC33816 Developer Studio User&#8217;s Guide - User&#8217;s Guide /docs/en/user-guide/MC33816DSWUG.pdf /docs/en/user-guide/MC33816DSWUG.pdf User Guide N 132339537837198660 2023-06-18 pdf N en Oct 6, 2015 132339537837198660 User Guide Y N MC33816DSWUG, MC33816 Developer Studio User&#8217;s Guide - User&#8217;s Guide 7 1.0 English The PSC (Programmable Solenoid Controller) Simulator is an integrated design/simulation environment for the firmware required by a family of NXP Programmable Solenoid Controllers (PSC). In this chapter, the main functions of the PSC simulator are listed, along with a suggested development cycle. 1403904176274714861465 PSP 3.3 MB None None documents None 1403904176274714861465 /docs/en/user-guide/MC33816SIMUG.pdf 3315271 /docs/en/user-guide/MC33816SIMUG.pdf MC33816SIMUG documents N N 2014-06-27 MC33816SIMUG, MC33816 PSC Simulator - User&#8217;s Guide /docs/en/user-guide/MC33816SIMUG.pdf /docs/en/user-guide/MC33816SIMUG.pdf User Guide N 132339537837198660 2023-06-18 pdf N en Jun 27, 2014 132339537837198660 User Guide Y N MC33816SIMUG, MC33816 PSC Simulator - User&#8217;s Guide Application Note Software Application Note Software 1 8 1.0 English Software example to drive four injectors managed in two banks, a single low pressure pump drive, and a variable frequency modulation (VFM) DC/DC converter. 1415311404196713676704 PSP 169.5 KB None None documents None 1415311404196713676704 /docs/en/application-note-software/AN4849SW.zip 169502 /docs/en/application-note-software/AN4849SW.zip AN4849SW documents N N 2019-10-02 AN4849SW, Software Files for AN4849 /docs/en/application-note-software/AN4849SW.zip /docs/en/application-note-software/AN4849SW.zip Application Note Software N 789425793691620447 2022-12-07 zip N en Oct 2, 2019 789425793691620447 Application Note Software Y N AN4849SW, Software Files for AN4849 Errata Errata 1 9 1.0 English This errata document applies to the MC33816 SMARTMOS<sup>&#174;</sup> product family. 1443219896420740470502 PSP 814.0 KB None None documents None 1443219896420740470502 /docs/en/errata/MC33816ER.pdf 813996 /docs/en/errata/MC33816ER.pdf MC33816ER documents N N 2015-09-25 MC33816ER, MC33816 Chip - Errata /docs/en/errata/MC33816ER.pdf /docs/en/errata/MC33816ER.pdf Errata N 155452329886410597 2022-12-07 pdf N en Oct 6, 2015 155452329886410597 Errata Y N MC33816ER, MC33816 Chip - Errata Fact Sheet Fact Sheet 1 10 2 English NXP&#8217;s programmable gate driver for solenoid control integrates microcores, external MOSFET high-side pre-drivers, and external MOSFET low-side pre-drivers. 1467309667594711938150 PSP 309.6 KB None None documents None 1467309667594711938150 /docs/en/fact-sheet/PT2000A4FS.pdf 309593 /docs/en/fact-sheet/PT2000A4FS.pdf PT2000A4FS documents N N 2016-10-31 Solenoid Programmable Gate Driver ICs (PT2000, PT2001 and MC33816) - Fact Sheet /docs/en/fact-sheet/PT2000A4FS.pdf /docs/en/fact-sheet/PT2000A4FS.pdf Fact Sheet N 736675474163315314 2022-12-07 pdf N en Aug 28, 2019 736675474163315314 Fact Sheet Y N Solenoid Programmable Gate Driver ICs (PT2000, PT2001 and MC33816) - Fact Sheet false 0 MC33816 downloads en true 1 Y PSP Y Y Application Note 3 /secured/assets/documents/en/application-note/AN4849.pdf 2016-10-31 1389907360154740727519 PSP 2 Jul 15, 2019 Application Note Example of a four cylinder internal combustion engine (ICE) injector drive. Registration without Disclaimer /secured/assets/documents/en/application-note/AN4849.pdf English documents 369909 None 645036621402383989 2022-12-07 Y /webapp/Download?colCode=AN4849 AN4849, Four injector and fuel pump drive - Application Note /secured/assets/documents/en/application-note/AN4849.pdf documents 645036621402383989 Application Note N en Extended Y pdf 5 Y N AN4849, Four injector and fuel pump drive - Application Note 369.9 KB AN4849 N 1389907360154740727519 /docs/en/application-note/AN4954.pdf 2014-06-19 1403195137764713068708 PSP 3 Feb 3, 2016 Application Note This application note explains how to use MC33816 diagnostics in a typical four cylinder internal combustion engine (ICE) application. None /docs/en/application-note/AN4954.pdf English documents 1109976 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN4954.pdf AN4954, MC33816 Diagnostics - Application Note /docs/en/application-note/AN4954.pdf documents 645036621402383989 Application Note N en None Y pdf 3.0 N N AN4954, MC33816 Diagnostics - Application Note 1.1 MB AN4954 N 1403195137764713068708 /docs/en/application-note/AN5203.pdf 2015-10-15 1444929321147694232840 PSP 4 Nov 18, 2015 Application Note MC33816 and PT2000 are programmable solenoid controllers used to drive external N Channel MOSFETs, and are mainly used to drive direct fuel injectors and valves. None /docs/en/application-note/AN5203.pdf English documents 323027 None 645036621402383989 2022-12-07 N /docs/en/application-note/AN5203.pdf AN5203, MC33816 vs. PT2000 - Application Note /docs/en/application-note/AN5203.pdf documents 645036621402383989 Application Note N en None Y pdf 1.0 N N AN5203, MC33816 vs. PT2000 - Application Note 323.0 KB AN5203 N 1444929321147694232840 Application Note Software 1 /docs/en/application-note-software/AN4849SW.zip 2019-10-02 1415311404196713676704 PSP 8 Oct 2, 2019 Application Note Software Software example to drive four injectors managed in two banks, a single low pressure pump drive, and a variable frequency modulation (VFM) DC/DC converter. None /docs/en/application-note-software/AN4849SW.zip English documents 169502 None 789425793691620447 2022-12-07 N /docs/en/application-note-software/AN4849SW.zip AN4849SW, Software Files for AN4849 /docs/en/application-note-software/AN4849SW.zip documents 789425793691620447 Application Note Software N en None Y zip 1.0 N N AN4849SW, Software Files for AN4849 169.5 KB AN4849SW N 1415311404196713676704 Data Sheet 1 /docs/en/data-sheet/MC33816.pdf 2016-10-31 1353093661081728217618 PSP 1 Feb 15, 2023 Data Sheet Data Sheet The 33816 is a SMARTMOS programmable gate driver IC for precision solenoid control applications. None /docs/en/data-sheet/MC33816.pdf English 4408774 None Data Sheet 2023-08-18 N /docs/en/data-sheet/MC33816.pdf MC33816, SD6 programmable solenoid controller for precision solenoid control applications - Data Sheet /docs/en/data-sheet/MC33816.pdf documents 980000996212993340 Data Sheet N Y en None Y t520 pdf 10.0 N N MC33816, SD6 programmable solenoid controller for precision solenoid control applications - Data Sheet 4.4 MB MC33816 N 1353093661081728217618 Errata 1 /docs/en/errata/MC33816ER.pdf 2015-09-25 1443219896420740470502 PSP 9 Oct 6, 2015 Errata This errata document applies to the MC33816 SMARTMOS<sup>&#174;</sup> product family. None /docs/en/errata/MC33816ER.pdf English documents 813996 None 155452329886410597 2022-12-07 N /docs/en/errata/MC33816ER.pdf MC33816ER, MC33816 Chip - Errata /docs/en/errata/MC33816ER.pdf documents 155452329886410597 Errata N en None Y pdf 1.0 N N MC33816ER, MC33816 Chip - Errata 814.0 KB MC33816ER N 1443219896420740470502 Fact Sheet 1 /docs/en/fact-sheet/PT2000A4FS.pdf 2016-10-31 1467309667594711938150 PSP 10 Aug 28, 2019 Fact Sheet NXP&#8217;s programmable gate driver for solenoid control integrates microcores, external MOSFET high-side pre-drivers, and external MOSFET low-side pre-drivers. None /docs/en/fact-sheet/PT2000A4FS.pdf English documents 309593 None 736675474163315314 2022-12-07 N /docs/en/fact-sheet/PT2000A4FS.pdf Solenoid Programmable Gate Driver ICs (PT2000, PT2001 and MC33816) - Fact Sheet /docs/en/fact-sheet/PT2000A4FS.pdf documents 736675474163315314 Fact Sheet N en None Y pdf 2 N N Solenoid Programmable Gate Driver ICs (PT2000, PT2001 and MC33816) - Fact Sheet 309.6 KB PT2000A4FS N 1467309667594711938150 User Guide 3 /docs/en/user-guide/KTPSCDEBUGUG.pdf 2015-11-19 1447957687765700483033 PSP 5 Nov 16, 2015 User Guide The PT2000 and MC33816 Developer Studio (IDE) software, and the KITPSCDEBUGEVM are used to configure, receive, and decode the trace codes coming from the device under test. None /docs/en/user-guide/KTPSCDEBUGUG.pdf English documents 3155664 None 132339537837198660 2022-12-07 N /docs/en/user-guide/KTPSCDEBUGUG.pdf KTPSCDEBUGUG, KITPSCDEBUG Evaluation Board - User&#8217;s Guide /docs/en/user-guide/KTPSCDEBUGUG.pdf documents 132339537837198660 User Guide N en None Y pdf 2.0 N N KTPSCDEBUGUG, KITPSCDEBUG Evaluation Board - User&#8217;s Guide 3.2 MB KTPSCDEBUGUG N 1447957687765700483033 /docs/en/user-guide/MC33816DSWUG.pdf 2015-01-15 1421361662470732669197 PSP 6 Oct 6, 2015 User Guide MC33816 Developer Studio is a Windows application created to streamline the development of micro code for the MC33816 Programmable Solenoid Controller. None /docs/en/user-guide/MC33816DSWUG.pdf English documents 2020372 None 132339537837198660 2023-06-18 N /docs/en/user-guide/MC33816DSWUG.pdf MC33816DSWUG, MC33816 Developer Studio User&#8217;s Guide - User&#8217;s Guide /docs/en/user-guide/MC33816DSWUG.pdf documents 132339537837198660 User Guide N en None Y pdf 2.0 N N MC33816DSWUG, MC33816 Developer Studio User&#8217;s Guide - User&#8217;s Guide 2.0 MB MC33816DSWUG N 1421361662470732669197 /docs/en/user-guide/MC33816SIMUG.pdf 2014-06-27 1403904176274714861465 PSP 7 Jun 27, 2014 User Guide The PSC (Programmable Solenoid Controller) Simulator is an integrated design/simulation environment for the firmware required by a family of NXP Programmable Solenoid Controllers (PSC). In this chapter, the main functions of the PSC simulator are listed, along with a suggested development cycle. None /docs/en/user-guide/MC33816SIMUG.pdf English documents 3315271 None 132339537837198660 2023-06-18 N /docs/en/user-guide/MC33816SIMUG.pdf MC33816SIMUG, MC33816 PSC Simulator - User&#8217;s Guide /docs/en/user-guide/MC33816SIMUG.pdf documents 132339537837198660 User Guide N en None Y pdf 1.0 N N MC33816SIMUG, MC33816 PSC Simulator - User&#8217;s Guide 3.3 MB MC33816SIMUG N 1403904176274714861465 true Y Products
