S12VR Mixed-Signal MCU for Automotive and Industrial Relay Based Motor Control

S12VR Active
S12 MagniV Microcontrollers for Automotive Applications

Click over video to play

The S12VR gives the smallest, efficient and scalable relay driven DC motor control solution for industrial and automotive applications such as window lift, sunroof.

It integrates the S12 16-bit microcontroller together with LIN Physical Interface, low side, and high-side drivers. High Voltage Input pins for 12 V switch interfaces, EVDD for sensor supply that reduce system, qualification and manufacturing cost.

Block Diagram

S12VR(P) Microcontroller

S12VR Microcontroller Block Diagram
Get diagram PDF

Features

  • S12 (25 MHz max) 16-bit CPU
  • 16 - 64kB Flash Memory with ECC
  • Voltage Regulator operating directly from the car battery
  • LIN Physical layer
  • 2 Low-side drivers (typ. for relay)
  • 1 Low-side driver (only in S12VRP)
  • 1-2 High-side drivers
  • 4-6 High Voltage Inputs for Switch Monitoring
  • On-chip RC Oscillator, trimmed to +/- 1,3% tolerance

Buy/Parametrics

1-10 of 20 results

Include 1 NRND

Part

Show description

Order

CAD Model

Status

Package Type

Package Termination Count

Budgetary Price excluding tax

Core Type

Operating Frequency [Max] (MHz)

Flash (kB)

RAM (kB)

EEPROM (kB)

Other Analog

PHY

GPIO

Number of LIN Channels

SCI

SPI

S9S12VR16F0CLC

Active

LQFP32

32

1K @ US$1.78

S12

25

16

2

0.13

1-ch. HS Driver

LIN

16

1

1

0

S9S12VR16F0MLC

Active

LQFP32

32

1K @ US$1.95

S12

25

16

2

0.13

1-ch. HS Driver

LIN

16

1

1

0

S9S12VR16F0VLC

Active

LQFP32

32

1K @ US$1.87

S12

25

16

2

0.13

1-ch. HS Driver

LIN

16

1

1

0

S9S12VR32F0CLC

Active

LQFP32

32

1K @ US$1.82

S12

25

32

2

0.13

1-ch. HS Driver

LIN

16

1

1

0

S9S12VR32F0MLC

Active

LQFP32

32

1K @ US$2.00

S12

25

32

2

0.13

1-ch. HS Driver

LIN

16

1

1

0

S9S12VR32F0VLC

Active

LQFP32

32

1K @ US$1.91

S12

25

32

2

0.13

1-ch. HS Driver

LIN

16

1

1

0

S9S12VR48AF0CLC

Active

LQFP32

32

1K @ US$2.68

S12

25

48

2

0.51

2-ch. HS Driver

LIN

12

1

2

1

S9S12VR48AF0CLF

Active

LQFP48

48

1K @ US$2.84

S12

25

48

2

0.51

2-ch. HS Driver

LIN

24

1

2

1

S9S12VR48AF0MLC

Active

LQFP32

32

1K @ US$2.95

S12

25

—

2

0.51

2-ch. HS Driver

LIN

16

1

2

1

S9S12VR48AF0MLF

Active

LQFP48

48

1K @ US$3.26

S12

25

48

2

0.51

2-ch. HS Driver

LIN

24

1

2

1
