S12XB Automotive and IndustrialMicrocontrollers (MCUs)

S12XB End of Life
  • This page contains information on a product that is not recommended for new designs.

The MC9S12XB is a general-purpose optimized feature/cost family for applications that require a reduced peripheral relative to the S12XD family.

Targeted for general automotive body applications, the MC9S12XB family is a fully compatible subset of the 9S12XD family.

Relative to the S12XD family, it has some functionality removed and speed reduced in order to deliver a significant cost savings.

Like the S12XD family, the S12XB is designed to retain the cost-effective, low-power consumption, excellent electromagnetic compatibility performance and code-size efficiency advantages associated with all 16-bit MCUs from NXP®.

S12XB Family Members: MC9S12XB256, MC9S12XB128.

Block Diagram

S12XB Microcontroller Block Diagram

S12XB Microcontroller Block Diagram
Get diagram PDF

Features

  • 16-bit CPU12X
  • Upward compatible with MC9S12 instruction set
  • Enhanced interrupt module
  • XGATE coprocessor
  • 128 KB to 256 KB flash EEPROM
  • 1 KB to 2 KB EEPROM
  • 6 KB to 10 KB RAM
  • 8 or 16-channel analog-to-digital converter (ADC), 8 or 10-bit resolution
  • 8-channel, 16-bit timer enhanced capture timer
  • 8-channel by 8-bit or 4-channel by 16-bit pulse width modulator
  • 1 Mbps, CAN 2.0 A, B software compatible
  • Two serial communications interface, one serial peripheral interface and two inter-integrated circuit interfaces

Buy/Parametrics

3 results

Exclude 3 NRND

Part

Show description

Order

CAD Model

Status

Package Type

Package Termination Count

Budgetary Price excluding tax

MC9S12XB128MAA
Data Sheet

End of Life

HQFP80

80

1K @ US$11.40
S912XB128F2CAL
Data Sheet

End of Life

LQFP112

112

—

S912XB256F1CAL
Data Sheet

End of Life

LQFP112

112

—
