TJA1153A Secure CAN Demo and Evaluation Board

UCANS32K1SCT

Roll over image to zoom in

The UCANS32K1SCT is an evaluation board for the TJA1153A Secure CAN Transceiver. The board comes with a secure CAN demo software pre-installed on the S32K146 microcontroller to play out different attack scenarios and demonstrate the security mechanisms built-in to the secure CAN transceivers.

The hardware development kit is fully equipped with all the accessories needed to get right into building your own software for integration into existing network architectures, including a debugger for flashing the software to the microcontroller and troubleshooting the software.

Supported Devices

Processors and Microcontrollers

S32K Auto General-Purpose MCUs

  • S32K1: S32K1 Microcontrollers for Automotive General Purpose

Interfaces

Secure CAN Transceivers

  • TJA1153: Secure HS-CAN Transceiver with Sleep Mode

Security and Authentication

Authentication

  • SE050: EdgeLock® SE050: Plug and Trust Secure Element Family – Enhanced IoT Security with High Flexibility

Features

UCANS32K1SCT Features

  • Dual CAN FD PHYs with dual connectors for daisy chain operation
  • PX4/DroneCode connector standard compliant
  • DCD-LZ debug interface with SWD+Console/UART
  • RGB LED
  • Programmable user buttons (e.g., for arming)

Interfaces

  • UART with full handshaking and 5 V/3 V switchable voltage level
  • SocketCAN CAN network driver
  • I²C, SPI
  • RC-PWM power output with internal or BEC/external power

Power

  • 5 V
  • Overcurrent protection

Runtime Software

  • S32 Design Studio IDE for Arm: SDK, Bare metal drivers and FreeRTOSTM
  • UAVCAN V1 protocol support: LibUAVCAN, LibCANARD
  • SLCAN interface supporting UAVCAN debug on PC
  • NuttX RTOS support
  • PX4 autopilot open source flight control vehicle stack

Buy Options

KIT-UCANS32K1SCT-Image

Click to expand

  • KIT-UCANS32K1SCT
    Active

  • TJA1153A Secure CAN Demo and Evaluation Board.

  • UCANS32K1SCT Development System

    Kit Contains:

    • 1 x UCANS32K1SCT board
    • 1 x CAN-TERM-BRD w/cable (RevB w MicroUSB) (for power supply via USB)
    • 1 x DCD-LZ debug adapter /w cable (small breakout board that can be connected to the UCANS32K1SCT; provides a JTAG/SWD 10 pin debug interface and a connector for the FTDI USB-UART cable)
    • 1 x FTDI USB-UART cable (to be connected to DCD-LZ debug adapter in order to have console access to the board via UART)
    • 1 x Segger Jlink mini EDU debugger (for programming and debugging; connected to JTAG/SWD 10 pin on the DCD-LZ debug adapter board)
    • 1 x CAN cable with both ends terminated (JST-GH 4 pin 200 mm, used for connecting both CAN channels on the board)
    • 1 x Standard CAN connection adapter for inspection device (JST-GH 4 to D-SUB 9 female according to CiA Standard 102 Version 2.0; for direct connection with e.g. a PCAN USB probe; can also be used to easily connect to an existing customer network)
    • Quick start guide
  • $114.63 USD
  • For a quantity of 1
    • Availability: In Stock
    • Inventory: 21
    • Shipping: Normally ships 1-2 business days
ADD TO CART
