FXPS7115D4 high-performance, high-precision Barometric Absolute Pressure sensor

For best experience this site requires Javascript to be enabled. To enable on your browser, follow our accessibility instructions.

FXPS7115DI4ST1 and FXPS7115DS4ST1 are the recommend devices for new designs as the FXPS7115DI4T1 and FXPS7115DS4T1 are discontinued.

The FXPS7115D4 high-performance, high-precision Barometric Absolute Pressure (BAP) sensor consists of a compact capacitive MEMS device coupled with a digital Integrated Circuit producing a fully calibrated digital output.

The sensor operates over a pressure range of 40 kPa to 115 kPa and a temperature range of −40°C to 130°C. Its AEC-Q100 compliance, high accuracy, reliable performance and high media resistivity make it ideal for use in automotive, industrial, and consumer applications.

See product image

Data Sheet

Application Notes

Product Details

Block Diagram

FXPS7115D4 Barometric Absolute Pressure (BAP) sensor

Get diagram PDF

Features

Key Features

Absolute pressure range: 40 to 115 kPa
Operating temperature range: –40°C to 130°C
Pressure transducer and digital signal processor (DSP)–Redundant pressure transducers– Digital self-test
I²C compatible serial interface–Follower mode operation–Standard mode, fast mode, and fast-mode plus support
32-bit SPI compatible serial interface - Sensor data transmission commands
32-bit SPI compatible serial interface for self-test access, user register access and device configuration
Capacitance to voltage converter with anti-aliasing filter
Sigma delta ADC plus sinc filter

Part numbers include: FXPS7115DI4, FXPS7115DI4S, FXPS7115DS4, FXPS7115DS4S.
