Scalable, Entry-Level 32-bit Microcontrollers (MCUs)

For best experience this site requires Javascript to be enabled. To enable on your browser, follow our accessibility instructions.

The LPC11xxLV MCU family is an Arm^® Cortex^®-M0 based low-cost 32-bit MCU family operating at CPU frequencies of up to 50 MHz. The LPC11xxLV MCU family is designed for 8/16-bit micro-controller operations, offering performance, low power, simple instruction set with reduced code size compared to existing 8/16-bit architectures.

The peripheral complement of the LPC11xxLV MCU family includes up to 32 KB of flash memory, up to 8 KB of SRAM, a fast-mode Plus I2C-bus interface, one UART, one SPI/SSP interface, four general purpose counters/timers, an 8-bit ADC, and up to 27 general purpose I/O pins.

Data Sheet

Application Notes

Product Details

Features

System

Arm Cortex-M0 processor, running at frequencies of up to 50 MHz
Arm Cortex-M0 built-in Nested Vectored Interrupt Controller (NVIC)
Serial wire debug
System tick timer

Memory

Up to 32 KB on-chip flash programming memory with a 256 byte page erase function
Up to 8 KB SRAM
In-system programming (ISP) and in-application programming (IAP) via on-chip bootloader software

Digital peripherals

Up to 27 general purpose I/O (GPIO) pins with configurable pull-up/pull-down resistors and a configurable open-drain mode
GPIO pins can be used as edge and level sensitive interrupt sources
High-current output driver on one pin
High-current sink drivers on two I2C-bus pins in fast-mode plus
Four general purpose counter/timers with a total of 7 capture inputs and 13 match outputs
Programmable windowed watch dog timer (WDT)

Analog peripherals

8-bit ADC with input multiplexing among 8 pins

Serial interfaces

UART with fractional baud rate generation and internal FIFO
One SPI controllers with SSP features and with FIFO and multi-protocol capabilities
I²C-bus interface supporting full I²C-bus specification and Fast-mode Plus with a data rate of 1 Mbit/s with multiple address recognition and monitor mode

Clock generation

12 MHz internal RC oscillator trimmed to 2.5 % accuracy for Tamb= -20 °C to +85 °C and to 5 % accuracy for Tamb = -40 °C to -20 °C. The IRC can optionally be used as a system clock
Crystal oscillator with an operating range of 1 MHz to 25 MHz
Programmable watchdog oscillator with a frequency range of 9.4 kHz to 2.3 MHz
PLL allows CPU operation up to the maximum CPU rate without the need for a high-frequency crystal. May be run from the system oscillator or the internal RC oscillator
Clock output function with divider that can reflect the system oscillator clock, IRC, CPU clock, and the Watchdog clock

Power control

Two reduced power modes: Sleep and deep-sleep mode
Ultra-low power consumption in deep-sleep mode
Processor wake-up from Deep-sleep mode via a dedicated start logic using up to 13 of the functional pins
Power-On Reset (POR)
Brownout Detection (BOD) causing a forced reset

Additional features

Device serial number for identification
Single power supply (1.65 V to 1.95 V)
Available as WLCSP25, HVQFN24, HQFN33

Part numbers include: LPC1101LVUK, LPC1102LVUK, LPC1112LVFHI33, LPC1112LVFHN24, LPC1114LVFHI33, LPC1114LVFHN24.
