Layerscape® Access LA12xx Programmable Baseband Processor
Contact NXP support or your sales representative for pricing and buying options.
The Layerscape Access LA12xx family of programmable baseband processors delivers high-performance digital signal processing capabilities, performance scalability and application flexibility for 5G sub-6 GHz and mmWave Fixed Wireless Access equipment such as Integrated Small Cells, O-RAN Distributed Unit and Radio Unit and Customer Premises Equipment (CPE). It can be also used in proprietary wireless applications such as defense and civilian radio systems and non-terrestrial networks (NTN).
The family is equipped with a unique combination of:
- High performance Vector Signal Processing Accelerators (VSPA)
- Forward Error Correction Accelerator (FECA)
- Integrated data converting subsystem (ADC/DAC)
For additional information and sample availability, contact NXP Support.
Product Details
Block Diagram
Features
Core and Memory Complex
- 6x 32-bit e200 Power® Architecture core complex @ 614.4 MHz
- Up to 8x VSPA3-16 @ 614.4 MHz (=1.3 TFLOP)
- 2MB On-Chip SRAM memory
Connectivity and I/O
- 2x PCIe Gen3 up to 8 lanes total
- 2x {I+Q} HS-DCS complex sampling rate of 1966.08 or 983.04 Msps
- Dual channel, <1GHz RF channel bandwidth at mmWave bands
- 4x {I+Q} LS-DCS complex sampling up to 491.52 Msps
- Four channel, <140 MHz RF channel bandwidth at sub-6 GHz bands
Acceleration
- Forward Error Correction Unit (FECU)
- 3GPP 5G/NR 38.212 compliant gNB and UE modes
- Polar decoder/encoder
- LDPC decoder/encoder
Device
- FC-PBGA package
Comparison Table
LA12xx Family Comparison Table
| Application | Device Family | Part Number | FECA | DSP-Cores | Low-Speed DCS | High-Speed DCS |
|---|---|---|---|---|---|---|
| O-DU | LA120x | LA1200 | N/A | N/A | ||
| LA1201 | 8x | |||||
| O-RU | LA121x | LA1212 | N/A | 8x | 2T2R | N/A |
| LA1214 | 8x | 4T4R | N/A | |||
| LA1215 | 8x | N/A | mmWave | |||
| LA1216 | 8x | 2T2R | 1*Rx Only | |||
| LA1218 | 8x | 4T4R | 2*Rx Only | |||
| FWA-CPE | LA122x | LA1223 | 8x | 2T2R | N/A | |
| LA1224 | 8x | Dual Use | Dual Use | |||
| LA1325 | 8x | N/A | mmWave | |||
| ISC | LA123x | LA1232 | 8x | 2T2R | N/A | |
| LA1234 | 8x | 4T4R | N/A | |||
| LA1235 | 8x | N/A | mmWave | |||
| LA1236 | 8x | 2T2R | 1*Rx Only | |||
| LA1238 | 8x | 4T4R | 2*Rx Only | |||
Software Support
NXP provides CodeWarrior, the Integrated Development Environment associated with Layerscape Access and many other NXP devices. Included in this environment is a multi-generational, mature compiler as well as access to a rich suite of existing software / signal processing libraries, examples and training material.
A broad ecosystem and comprehensive development platform support is essential to ease development and speed time to market for a commercial grade 3GPP Stacks. All L1 and L2/+ software stack is available from NXP and/or partners depending on the device category and other requirements.
Hardware Tools
Customers can implement and develop their applications with LA12xx evaluation hardware. The LA12xx Evaluation Board is a combination of NXP LX2160 multicore Arm® processor as host and LA12xx modem as baseband for 5G-NR Fixed Wireless applications. The boards come with pre-loaded board support package (BSP) based on a standard Linux kernel.
