3.0 MHz, 500 MA, DC-to-DC Boost Converter
The PCA9410 and PCA9410A are highly efficient 3.0 MHz, 500 mA, step-up DC-to-DC converters. They convert input voltages from 2.5 V to 5.25 V to a fixed output voltage of 5.0 V.
These devices are optimized for battery-powered applications. High efficiency of up to 94 % enables an extended battery life in all portable designs. Step-up operation at a switching frequency of 3 MHz allows using 1 µH inductor or smaller.
Product Details
Features
- Efficiency up to 94 %
- ±3 % output voltage accuracy at nominal and static conditions
- ±3 % output voltage accuracy over full current, voltage and temperature range
- VIN ≥ VO, (Pass-Through Mode Operation)
- Load disconnect
- Current-mode controller
- Soft start function for limiting inrush current with true load disconnect
- Reverse current, overcurrent and over-temperature protection
- The PCA9410 totally disconnects input to output when disabled
- The PCA9410A connects input to output when disabled
- Wafer-Level Chip-Size Package (WLCSP) with 0.4 mm pitch; allows for the use of a smaller antenna, or for greater signal strength
Target Applications
- Smartphones
- NFC terminals
Buy/Parametrics
1 result
Include 1 NRND
Part | Order | CAD Model | Status | Budgetary Price excluding tax |
|---|---|---|---|---|
Active | 10K @ US$0.39 |
