NFC Forum-Compliant Tag IC with I2C for Automotive
The NCx3310 is a versatile tag IC offering a wide variety of features to address multiple automotive applications.
NCx3310 allows for implementing a cost-effective NFC interface with a wired host interface that is configurable as an I²C leader/follower for automotive use cases. It is an NFC Forum-compliant contactless tag that can be read and written by an NFC-enabled device at close range and by an ISO/IEC 15693-enabled industrial reader over a longer range.
NCx3310 Automotive Tag offers:
- Reading distance: >5 cm with mobile phones and >60 cm with long-range readers
- Zero-power readout of an I²C sensor
- Energy-efficient design with reduced bill of materials
- Long battery life due to low standby current and hard power-down pin
- Antenna size reduction by a factor of 40 in active load modulation (ALM), same read range as in passive load modulation (PLM)
Please send us an email to request product support packages for this product.
Once you have your activation code, please see how to register and activate software
Product Details
Features
Key Features
- I²C leader and follower channel
- AES mutual authentication
- Passive load modulation (PLM) and active load modulation (ALM)
- Energy harvesting
NFC Interface
- Fully NFC Forum-compliant type 5 tag
- ISO/IEC 15693 compliant
- 8-byte unique identifier
- 32-byte reprogrammable originality signature
Host Interface
- I²C follower and listener interface supports up to 400 kHz
- 2 GPIO’s
- Event detection pin
Scalable Security
- AES 128-bit mutual authentication
- 32/64-bit password protection
- Read-only locking
- NFC silence mode
- 3 configurable user memory areas
- ECC-based reprogrammable originality signature
Memory
- 2048 bytes user memory
- 256 bytes SRAM
Power Consumption
- Low standby power consumption: <6 μA standby
- Low hard power-down power consumption: <0.25 μA
