PF5020 Multi-Channel (5) PMIC Evaluation Board

KITPF5020FRDMEVM Active

Roll over image to zoom in

The KITPF5020FRDMEVM is a customer evaluation board/kit featuring the PF5020 power management IC.

The kit integrates all hardware needed to fully evaluate the featured power management integrated circuit. It integrates a communication interface based on the FRDM-KL25Z freedom board to interface with the NXP GUI software to fully configure and control the PF5020 PMIC.

Supported Devices

Power Management

PMICs

  • PF5020: Multi-Channel (5) PMIC for Automotive Applications – 4 High Power and 1 Low Power, Fit for ASIL B Safety Level

Features

PMIC

  • Multi-Output
  • OTP Programmable
  • Fit to ASIL B Safety Level

Software Interface

  • FRDM-KL25Z Board

Connectivity

  • High-Speed I²C through KL25Z

Jumpers and Switches

  • PMIC Enable and IO Control

LEDs

  • PGOOD Indication

Buy Options

KITPF5020FRDMEVM-Image

Click to expand

  • KITPF5020FRDMEVM
    Active

  • PF5020 Multi-Channel (5) PMIC Evaluation Board .

    • Assembled and tested KITPF5020FRDMEVM
    • Preprogrammed FRDM-KL25Z
    • 3.0 ft. USB-STD A to USB-B-mini cable
  • $147.77 USD
  • For a quantity of 1
    • Availability: In Stock
    • Inventory: 5
    • Shipping: Normally ships 1-2 business days
