TWR-MCF51AG-KIT Schematic
ColdFire MCF51AG Tower System Module
The TWR-MCF51AG is part of the Tower® System, a modular development platform that enables rapid prototyping and tool re-use through reconfigurable hardware.
The TWR-MCF51AG tower system can operate as a standalone debug tool and can be purchased separately as a kit, part number TWR-MCF51AG-KIT, including the TWR-MCF51AG module, TWR-PROTO and TWR-ELEV.
Product Details
Supported Devices
Processors and Microcontrollers
ColdFire+ MCUs
- MCF51AG: 32-Bit ColdFire V1 Microcontrollers
Features
Connectivity
- Mini-B USB Connector
- Includes power regulation circuitry with standardized bus
Debug
- Integrated open source BDM debugging tool
Sensors
- MPR121 Touch Sensor
- 3-axis Accelerometer Sensor
Support
- Supports external communications interfaces
Size
- Small form factor
User Components
- Potentiometer
- 4 LEDs
- Capacitive Touch Pads
