Trimension™ SR150: Secure UWB Solution for IoT Devices
Designed with the specific needs of IoT devices in mind, Trimension SR150 adds Angle-of-Arrival (AoA) technology for an added level of precision. The integrated FiRa™ MAC by NXP supports interoperability with the growing set of UWB devices to market. As the latest development, it also offers interoperability with Apple U1 chipset with firmware v.3.14.0.
Trimension SR150 is ideally suited for the UWB enablement of all kinds of larger infrastructures, such as access control installations, indoor localization set ups and payment schemes, as well as consumer products, including TVs and gaming consoles. Several SR150 IC devices can be placed in a room as UWB anchors to help localize people and objects as they move within the room.
NXP achieves excellent precision and robustness with its broad UWB portfolio and was first to offer a system-level UWB solution backed by a comprehensive software offering and strong security integration based on NXP’s market-proven embedded secure elements (eSEs).
Product Details
Features
- Apple MFi certification and interoperability with Apple U1 chip with firmware (v.3.14.0)
- Dual-RX for AoA functionality
- 3D AoA capable
- Can be connected to EdgeLock® SE051W for secure ranging use cases
- RTOS and Linux SW Solution for IoT integration
- Industry first FiRa certified chipset
- IEEE 802.15.4z compatible
- Arm® Cortex®-based
Related products
Trimension™ NCJ29D5: UWB IC for Automotive Applications
Buy/Parametrics
1 result
Include 0 NRND
Part | Order | CAD Model | Status | Budgetary Price excluding tax | Ambient Operating Temperature (Min to Max) (℃) | Device Function | Supply Voltage [Typ] (V) | Supply Voltage [Min to Max] (V) |
|---|---|---|---|---|---|---|---|---|
Active | 1K @ US$3.96 | -30 to 85 | UWB based ranging and communication | 1.8 | 1.71 to 1.98 |
2 documents
Compact List
Data Sheet (1)
Fact Sheet (1)
Design Resources
Hardware
Quick reference to our
board types.
4 hardware offerings
-
Evaluation and Development BoardsTrimension™ SR150 UWB Module: Murata Type2BP
-
Evaluation and Development BoardsMurata Type2BP EVK: Trimension™ SR150 UWB Development Kit
-
Evaluation and Development BoardsAutonomous Secure Access Solution
Preproduction -
Additional hardware available. View our featured partner solutions.
-
Evaluation and Development BoardsWeikeng UWB EVK-2: UWB Evaluation Kit for the Trimension™ SR150-Based UWB Module
Engineering Services
To get further assistance directly from NXP, please see our Engineering Services.
1 engineering service
To find additional partner offerings that support this product, visit our Partner Marketplace.
