TWR-S08LH64-KIT Base Board Schematics
MC9S08LH 8-bit Segment LCD Tower System Module
The TWR-S08LH64 module is a development board for the MC9S08LH64 segment LCD controller that features a 3-axis accelerometer ADC input and a 2x28 segment LCD display. The integrated OSBDM allows a designer to communicate with the board and target device using only a USB cable.
The TWR-S08LH64 operates as a standalone debug tool and can also be combined and used as part of the modular Tower® System development platform.
Product Details
Supported Devices
Processors and Microcontrollers
8-Bit S08 MCUs
- S08LH: 8-bit with LCD Driver LH MCUs
Features
Microcontroller
- MC9S08LH64 MCU
- 32,768 Hz Crystal
Connectivity
- Mini-B USB connector
- RS-232 port
- NXP® 3-axis accelerometer ADC input to MCU
Sensors
- Light sensor with LP filter and op amp
Display
- 2 x 28 segments LCD display
- The TWR-S08LH64 board contains a MC9S08LL, an Energy-Efficient Product Solution by NXP
User Components
- 5 K One Turn Potentiometer
- Buzzer
- 1 reset push button and 4 push switches
