BGU8103 GNSS LNA evaluation board

Roll over image to zoom in

Supported Devices

RF

Legacy RF Low-Medium Power Amplifiers

Features

  • Covers full GNSS L1 band, from 1559 MHz to 1610 MHz:
    • Noise figure (NF) = 0.9 dB
    • Gain = 17.5 dB
    • High input 1 dB compression point of -13 dBm
    • High out of band IP3i of -7 dBm
    • Supply voltage 1.5 V to 3.1 V
    • Optimized performance at low supply current of 1.2 mA
    • Power-down mode current consumption < 1 µA
    • Integrated temperature stabilized bias for easy design
    • Requires only one input matching inductor and one supply decoupling capacitor
    • Input and output DC decoupled
    • ESD protection on all pins (HBM > 2 kV)
    • Integrated matching for the output
    • Available in a plastic extremely thin and small outline 6-pins leadless package: 1.1 mm x 0.7 mm x 0.37 mm; 0.4 mm pitch: SOT1232
    • 180 GHz transit frequency - SiGe:C technology

Buy Options

OM7896-Image

Click to expand

  • OM7896
    Active

  • BGU8103 GNSS LNA evaluation board.

  • For a quantity of 1
