32-bit Power Architecture® Microcontrollers

MPC5121e Not Recommended for New Designs

NXP ® MPC5121e and MPC5123 MCUs provide an excellent computing platform for OEM, aftermarket, commercial telematics and consumer applications—including embedded solutions requiring network connectivity, graphics and a graphical user interface.

  • Optimal for applications such as automotive center stack systems
  • An array of I/Os and dedicated cores reduces bill-of-materials costs while improving functionality
  • Offers competitive cost, quality, reliability and excellent performance
  • Includes widespread mobileGT ® alliance firmware and software driver support
  • Supports real-time operating systems (Green Hills, QNX and Wind River, Linux®)

Block Diagram

Freescale mobileGT MPC5121E Microcontroller Block Diagram

NXP<sup>&#174;</sup> mobileGT<sup>&#174;</sup> MPC5121E Microcontroller Block Diagram
Get diagram PDF

Features

  • e300 core built on Power Architecture technology
  • Up to 400 MHz performance and 760 MIPS
  • AXE, a 32-bit RISC audio accelerator engine
  • PowerVR® MBX Lite 2D/3D Graphics Engine (not included in the MPC5123)
  • DIU integrated display controller supports up to XGA resolution
  • 12 programmable serial controllers (PSC)
  • This product is included in NXP®.s product longevity program, with assured supply for a minimum of 15 years after launch

Buy/Parametrics

2 results

Exclude 2 NRND

Part

Show description

Order

CAD Model

Status

Package Type

Package Termination Count

MPC5121YVY400B
Data Sheet

Not Recommended for New Designs

HBGA516

516

MPC5123YVY400B
Data Sheet

Not Recommended for New Designs

HBGA516

516
