SOT1756-1: SENSOR4F

Overview

SENSOR4F, sensor package; 4 terminals; 2.54 mm pitch; 17.78 mm x 29.48 mm x 10.67 mm body

Package Version	Package Name	Mount	Terminal Position	Package Style	Dimensions	Termination Count	Material
SOT1756-1	SENSOR4F	through-hole mount	double		17.78 x 29.48 x 10.67	4

Manufacture Code	Reference Codes	Issue Date
98ASB42797B	E-PSXC-F6(JEDEC	2017-06-11

Products

Part	Description	Quick access
MPX5010GSX	PRES SEN INTEG 10KPA	View parametrics
MPX5050DP	Pressure Sensor, 5V, 0/50kPa, Sensor 6, Port	View parametrics
MPX5700DP	Pressure Sensor, 5V, 0/700kPa, Sensor 6, Port	View parametrics
MPX4250DP	Pressure Sensor, 5.1V, 0/250kPa, Sensor 6, Port	View parametrics
MPX5500DP	Pressure Sensor, 5V, 0/500kPa, Sensor 6, Port	View parametrics
MPX5100DP	Pressure Sensor, 5V, 0/100kPa, Sensor 6, Port	View parametrics
MPX5700ASX	Pressure Sensor, 5V, 15/700kPa, Sensor 6, Port	View parametrics
MPX5010DP	Pressure Sensor, 5V, 0/10kPa, Sensor 6, Port	View parametrics
