Battery Powered Portable Device Design Based on i.MX 8ULP
NXP’s iMX 8ULP-based protable device reference design can optionally be powered by a lithium battery. This enables developers to quickly and easily implement many designs, including smart watches, on this reference design platform. This reference design provides developers with a low-power, small form factor design example that enables fast out-of-the-box operation, minimizing time to market, risk and development effort.
For more detail, please visit UG10094.
Product Details
Supported Devices
Sensors
Barometric Pressure 15 to 150 kPa
- MPL3115A2: Absolute Digital Pressure Sensor (20 to 110 kPa)
Power Management
PMICs
- PCA9460: 13-Channel Power Management Integrated Circuit (PMIC) for Ultra Low Power Application
Interfaces
USB Interfaces
- PTN5150: CC Logic for USB Type-C Applications
Wireless Connectivity
Wi-Fi® + Bluetooth® + 802.15.4
- IW416: 2.4/5 GHz Dual-Band 1x1 Wi-Fi® 4 (802.11n) + Bluetooth® 5.2 Solution
Processors and Microcontrollers
i.MX 8 Applications Processors
- i.MX8ULP: i.MX 8ULP Applications Processor Family
Features
Processor
- NXP i.MX 8ULP applications processor
Memory
- eMCP: 2GB LPDDR4x + 32GB eMMC
PMIC
- NXP PCA9460B: 13-Channel PMIC for Ultra Low Power Application
Display
- 1.39” Full color round AMOLED with touch
Wireless
- Murata Type 1XK (NXP IW416) Shielded Ultra Small Dual band Wi-Fi® 11a/b/g/n + Bluetooth® 5.2 Module
Audio
- 2x Digital MIC
- 1x Speaker (connects to MQS)
Connectivity
- NXP PTN5150: USB 2.0 Type C
- NXP SN110T NFC
Sensors
- NXP MPL3115A2: I2C precision pressure sensor with altimetry
- High-Sensitivity Pulse Oximeter and Heart-Rate Sensor
- Light-to-Digital Sensor
Debug
- FT4232 (Port A- JTAG, Port B- I2C, Port C- A35 Debug UART, Port D-M33 Debug UART)
- JTAG
- Support online real-time power measurement. (by bcu tool)
Tools and OS support
- Android
- FreeRTOS
