- Oct 6, 2016
About This Video
This video give a tutorial on the LPC Initialization tool from NXP® (http://www.lpcware.com/content/tools/lpc-initializer) which allows users to configure the pinmuxing of the LPC800 via the Switch matrix as well configuring the IO CON block with a simple graphical interface. Additionally, the video demonstrates how to use the different aspects of the tool to configure an LPC812.
To leave feed back on the tool, join the LPC800 forum at: http://www.lpcware.com/content/forum/web-based-lpc800-configuration-tool
From more information about the LPC800 go to http://www.nxp.com/microcontrollers
