The KEA128AUTONETRD is a reference design for a central gateway that works as a communications bridge between LIN and CAN.

Based on the 32-bit Arm^® Cortex^®-M0+ KEA128 automotive-grade MCU, the KEA128AUTONETRD offers efficient and accurate bus processing and energy-saving capabilities.

Design Files

Software

Product Details

Block Diagram

Green Automotive Networking

Get diagram PDF

Features

FEATURES

The Green Auto Network solution uses the TRK-KEA128 development board
CodeWarrior^® driver library offers efficient and convenient assistance in design

INTERFACES

LIN communications interface10 PN7462 samples
SCI serial communication interface (shares the OpenSDA interface)
CAN communications interface
Analog interface with ambient light sensor
