Gerber files for the KIT33771ASP1EVB Evaluation board
- No Longer Manufactured
- Evaluation Board, MC33771: 14 Channel Li-ion Battery Cell Controller IC
Evaluation Board, MC33771: 14 Channel Li-ion Battery Cell Controller IC
- This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.
The KIT33771ASP1EVB is a hardware tool to evaluate the MC33771, 14 channel lithium ion Battery Cells Controller IC designed for automotive and industrial applications.
- Ideal for rapid prototyping of applications for current, voltage and temperature sensing
- Performs ADC conversion on the differential cell voltage and currents as well battery charge coulomb counting and battery temperature measurements
- Includes a transformer to communicate in a high speed isolated communication network; information is digitally transmitted to a MCU for processing
Archived content is no longer updated and is made available for historical reference only.
