Dual-Channel Programmable Angle Sensor

KMA220 No Longer Manufactured
  • This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.

Roll over image to zoom in

The KMA220 is a high precision dual channel magnetic angle sensor for magnetic angular measurement. The MagnetoResistive (MR) sensor bridges, the mixed signal Integrated Circuits (ICs) and the required capacitors are integrated into a single package. Both integrated channels are working full independently. The supply voltage has common terminals. Further explanations are referring to a single channel of the KMA220.

This angular measurement module KMA220 is pre-programmed, pre-calibrated and therefore, ready to use.

The KMA220 allows user-specific adjustments of angular range, zero angle and clamping voltages for each channel separately. The settings are stored permanently in a non-volatile memory.

Product Details

Features

Key Features

  • High precision sensor for magnetic angular measurement
  • Single package dual channel sensor module with integrated filters for improved ElectroMagnetic Compatibility (EMC)
  • Automotive qualified in accordance with AEC-Q100 Rev-G
  • Fail-safe non-volatile memory with write protection using lock bit
  • Independent from magnetic field strength above 35 kA/m
  • Ready to use without external components
  • One common supply line
  • High temperature range up to 160 °C
  • Dual electric independent sensor channels with analog ratiometric output voltages
  • Overvoltage protection up to 16 V
  • Independent programming via separated One-Wire Interfaces (OWI)
  • Each channel includes user-programmable 32-bit identifier
  • Magnet-loss and power-loss detection
  • Factory calibrated
