ATM Cell Processor

MC92501

Roll over image to zoom in

The MC92501 is an ATM layer device composed of dedicated high-performance ingress and egress cell processors combined with UTOPIA Level 2-compliant physical (PHY) and switch interface ports. The MC92501 is a second generation ATM cell processor in the MC92500 Series.

The ATMC software development board contains all the devices necessary to build an OC-3 line card. The contents include the following:

  • ATM Cell Processor for ATM layer functionality (i.e., policing, OAM, statistic gathering, address translation)
  • MPC860SAR for embedded control and low bandwidth SARing for in-band signaling
  • CAM for VCI/VPI address translation tables (MCM69C232)
  • Asynchronous FStatic for context table storage (MCM6226BB)

In addition, the board contains a UTOPIA L2 PHY bus and a UTOPIA switch bus for connecting the development board to other devices. Traffic generators and recorders are included on the board for the initial stages of debug.

For more information on the ATMC Development Kit, or to place an order, please contact your local NXP® sales representative.
