- No Longer Manufactured
- MRF8P9210N
920-960 MHz, 63 W Avg., 28 V Single W-CDMA RF Power LDMOS Transistor
- This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.
The MRF8P9210NR3 is designed for CDMA base station applications with frequencies from 920 to 960 MHz. Can be used in Class AB and Class C for all typical cellular base station modulation formats.
Product Details
RF Performance Table
900 MHz
Typical Doherty Single-Carrier W-CDMA Characterization Performance: VDD = 28 Volts, IDQA = 750 mA, VGSB = 1.2 Vdc, Pout = 63 Watts Avg., IQ Magnitude Clipping, Channel Bandwidth = 3.84 MHz, Input Signal PAR = 7.5 dB @ 0.01% Probability on CCDF.| Frequency | Gps (dB) |
ηD (%) |
Output PAR (dB) |
ACPR (dBc) |
| 920 MHz | 16.5 | 46.2 | 6.2 | –31.3 |
| 940 MHz | 16.9 | 47.7 | 6.0 | –32.6 |
| 960 MHz | 16.7 | 47.4 | 5.8 | –34.4 |
- Capable of Handling 10:1 VSWR, @ 32 Vdc, 960 MHz, 253 Watts CW Output Power (3 dB Input Overdrive from Rated Pout), Designed for Enhanced Ruggedness
- Typical Pout @ 3 dB Compression Point ≃ 290 Watts
