- No Longer Manufactured
- MMA1254EG
±5g, Low-g, Analog Accelerometer
- This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.
The MMA1254 series of silicon capacitive, micro-machined accelerometer features signal conditioning, two-pole low-pass filter, and temperature compensation.
- Targets industrial applications such as vibration recording, mechanical bearing monitoring, hard drive protection, mouse/joysticks, virtual reality input, and sport diagnostics
- Includes factory-set zero-g offset full-scale span and filter cut-off; requires no external devices
- Verifies system functionality via full-system self-test capability
Product Details
Features
- Integral signal conditioning
- Linear output
- Second-order Bessel filter
- Calibrated self–test
- EPROM parity check status
- Transducer hermetically sealed at wafer-level for superior reliability
- Robust design, high shock survivability
- Sensing direction is z-axis
Part numbers include: MMA1254KEG.
