24-bit Symphony® DSP

DSP56364 End of Life

Roll over image to zoom in

The DSP56364 is a low-cost, high-performance DSP optimized for cost sensitive consumer audio applications. The DSP56364 provides a cost-effective silicon solution for applications such as Dolby Pro Logic A/V receivers, televisions, and minisystems, in addition to automotive and portable applications. The DSP56364 has sufficient on-chip performance and memory to simultaneous support a variety of audio software algorithms such as Dolby Pro Logic, soundfield processing, 3D virtual surround, graphic/parametric equalization, and spectrum analysis.

The DSP56364 is the second product in the DSP56300 audio Symphony® DSP family and utilizes the single-instruction-per-clock-cycle DSP56300 core while retaining DSP56000 code compatibility. The DSP56364 reuses peripherals from the first DSP56300 audio product, the DSP56362. The DSP56364 will support 100 MIPS at 3.3 V.
