2110-2170 MHz, 50 W Avg., 28 V Airfast® RF Power LDMOS Transistor
- No Longer Manufactured
- AFT21S230S
2110-2170 MHz, 50 W Avg., 28 V Airfast® RF Power LDMOS Transistor
- This page contains information on a product that is no longer manufactured (discontinued). Specifications and information herein are available for historical reference only.
The AFT21S230SR3 50 W RF power LDMOS transistor is designed for cellular base station applications covering the frequency range of 2110 to 2170 MHz.
Product Details
RF Performance Table
2100 MHz
Typical Single-Carrier W-CDMA Performance: VDD = 28 Vdc, IDQ = 1500 mA, Pout = 50 W Avg., Input Signal PAR = 9.9 dB @ 0.01% Probability on CCDF.| Frequency | Gps (dB) |
ηD (%) |
Output PAR (dB) |
ACPR (dBc) |
IRL (dB) |
| 2110 MHz | 16.7 | 30.5 | 7.2 | –35.7 | –19 |
| 2140 MHz | 17.0 | 31.0 | 7.1 | –35.4 | –20 |
| 2170 MHz | 17.2 | 31.8 | 7.0 | –34.8 | –15 |
