Differential and Gauge Compensated Pressure Sensor (0 to 50 kPa)
The MPXx2050 series delivers silicon piezoresistive pressure sensors for use in a wide selection of medical and industrial devices.
- Provides a highly accurate and linear voltage output directly proportional to the applied pressure.
- Includes a single monolithic silicon diaphragm with the strain gauge and a thin-film resistor network integrated on-chip
- Offers a laser-trimmed chip for precise span, offset calibration and temperature compensation
Product Details
Features
Key Features
- Temperature compensated over 0° to +85 °C
- Silicon shear stress strain gauge
- Available in rails or tape-in-reel shipping options
- Ratiometric to supply voltage
- Differential and gauge options
- ±0.25 percent linearity
