i.MX 6ULL Single-Core Processor with Arm® Cortex®-A7 Core

Webinar On-demand: Introducing the new Colibri SoM based on the NXP i.MX 6ULL SoC

Click over video to play

Block Diagram

i.MX 6ULL Block Diagram

i.MX 6ULL Block Diagram

Features

CPU Complex

  • Cortex-A7 core up to 900 MHz, 128 KB L2 cache

Display

  • Parallel LCD Display up to WXGA (1366x768)
  • 8/10/16/24-bit Parallel Camera Sensor Interface
  • Electrophoretic display controller support direct-driver for E-Ink EPD panel, with up to 2048x1536 resolution at 106 Hz

Memory

  • 16-bit LP-DDR2, DDR3/DDR3L
  • 8/16-bit Parallel NOR FLASH / PSRAM
  • Dual-channel Quad-SPI NOR FLASH
  • 8-bit Raw NAND FLASH with 40-bit ECC

Connectivity

  • 2x MMC 4.5/SD 3.0/SDIO Port
  • 2x USB 2.0 OTG, HS/FS, Device or Host with PHY
  • Audio Interfaces include 3x I2S/SAI, S/PDIF Tx/Rx
  • 2x 10/100 Ethernet with IEEE 1588
  • 2x 12-bit ADC, up to 10 input channel total, with resistive touch controller (4-wire/5-wire)

Advanced Power Management

  • Partial PMU Integration

Security

  • Security Block: TRNG, Crypto Engine (AES with DPA, TDES/SHA/RSA), Secure Boot

Package

  • 14x14 289 MAPBGA 0.8mm pitch
  • 9x9 272 MAPBGA 0.5 mm pitch

More

Buy/Parametrics

1-10 of 14 results

Include 0 NRND

Order

CAD Model

Status

Package Termination Count

Package Type

Package Pitch (mm)

Core: Number of cores (SPEC)

Core Type

Operating Frequency [Max] (MHz)

External Memory Supported

Video/Display features

L2 Cache (Max) (KB)

SRAM (kB)

SPI

I2C

UART

USB Controllers

CAN

Junction Temperature (Min) (℃)

Junction Temperature (Max) (℃)

Audio Specific Modules

GPU 2D / GPU 3D

Active

289

LFBGA289

0.8

1

Arm Cortex-A7

528

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

128

2

2

4

1

-40

105

Active

289

LFBGA289

0.8

1

Arm Cortex-A7

528

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

128

2

2

4

1

0

95

Active

272

LFBGA272

0.5

1

Arm Cortex-A7

528

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

128

128

4

4

8

2

-40

105

Active

289

LFBGA289

0.8

1

Arm Cortex-A7

528

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

128

128

4

4

8

2

-40

105

Active

272

LFBGA272

0.5

1

Arm Cortex-A7

528

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

128

128

4

4

8

2

0

95

Active

289

LFBGA289

0.8

1

Arm Cortex-A7

528

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

128

128

4

4

8

2

0

95

Active

272

LFBGA272

0.5

1

Arm Cortex-A7

800

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

128

128

4

4

8

2

-40

105

SPDIF

Active

289

LFBGA289

0.8

1

Arm Cortex-A7

528

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

RGB

128

128

4

4

8

2

-40

105

Active

289

LFBGA289

0.8

1

Arm Cortex-A7

800

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM, SD3.0/eMMC4.5

128

128

4

4

8

2

2

-40

105

PXP Engine

Active

272

LFBGA272

0.5

1

Arm Cortex-A7

900

DDR3 SDRAM, DDR3L SDRAM, LPDDR2 DRAM

128

128

4

4

8

2

0

95

SPDIF
