2x2 Tri-band (2.4G/5/6 GHz) Wi-Fi® 6E and Bluetooth Combo Solution
2x2 Dual-Band (5-7 GHz), 1x1 (2.4 GHz) Concurrent Dual Wi-Fi 6/6E and Bluetooth® 5.3 Combo Solution
The AW693 is a highly integrated Wi-Fi 6/6E device enabling concurrent dual Wi-Fi (CDW) and Bluetooth® 5.3 operation. AW693 supports four modes:
- Mode 1: CDW 2x2 Wi-Fi 6/6E 5-7 GHz (802.11ax) + 1x1 Wi-Fi 6 2.4 GHz (802.11ax)
- Mode 2: CDW 1x1 Wi-Fi 6/6E 5-7 GHz (802.11ax) + 1x1 Wi-Fi 6 2.4 GHz (802.11ax)
- Mode 3: 2x2 Wi-Fi 6 2.4 GHz (802.11ax)
- Mode 4: 2x2 Wi-Fi 6/6E 5-7 GHz (802.11ax)
The System-on-Chip (SoC) implements advanced features including multi-user multiple-input multiple-output (MU-MIMO), orthogonal frequency-division multiple access (OFDMA), Target Wake Time (TWT) and Bluetooth Low Energy (LE) Audio. The AW693 integrates 2.4 GHz and 5 GHz TX power amplifiers (PA), RX low-noise amplifiers (LNA) and Tx/Rx switches (T/R SW). It also includes a full Bluetooth radio, simplifying design. This solution also supports three-antenna design and an external front-end module (FEM).
The AW693 supports a flexible front-end design with either three or two antennas. The AW693 implements advanced real-time Wi-Fi and Bluetooth arbitration hardware in conjunction with software algorithms to optimize coexistence performance.
NXP’s EdgeLock® technology is integrated. The embedded Edgelock secure subsystem (ELS) supports hardware crypto accelerated secure boot, key management, firmware authentication, secure lifecycle management and anti-rollback protection.
The AW693 integrates dedicated CPUs and memories for both the Wi-Fi and Bluetooth subsystems for real-time, independent protocol processing. The interfaces to external host processors include peripheral component interconnect express (PCIe) for Wi-Fi and universal asynchronous receiver-transmitter (UART) for Bluetooth. The AW693 is available in high-volume quad flat no-lead, 148 pins (HVQFN148) and wafer level chip scale package (WLCSP) packages and is AEC-Q100 Grade 2 compliant.
Wireless modules based on the NXP AW693 are offered by leading module manufacturers.
Product Details
Features
Wi-Fi Specifications
- 2x2 Wi-Fi 6/6E and 1x1 Wi-Fi 2.4 GHz CDW mode (mode 1)
-
2x2 radio
- 40 MHz channel for 2.4 GHz (radio frequency, or RF paths: 2A/2B)
- 1024 quadrature amplitude modulation (QAM) modulation and coding scheme 11 (MCS11), up to 80 MHz channel for 5-7 GHz (RF paths: 5 A/5 B)
-
1x1 radio
- 20 MHz channel for 2.4 GHz (RF paths: C)
- 1024 QAM (MCS11), up to 80 MHz channel for 5-7 GHz (RF paths: 5 A)
-
2x2 and 1x1 radios
- Station (STA) and mobile access point (AP)
- Low-latency data exchange (LLDE)
- Wi-Fi timing synchronization function (TSF) host clock sync between AP and STA
- PCIe host interface
Bluetooth Capabilities
- Bluetooth 5.3
- High-speed, long-range and advertising extensions
- Isochronous channels supporting Bluetooth LE audio
- Integrated PA (+13 dBm)/LNA/switch(SW)
- Optional external PA/LNA
- UART host interface
Operating Characteristics
- Supply voltage: 1.8 V and 3.3 V
- Operating temperature: Automotive AEC-Q100 Grade 2: -40 °C to 105 °C
- Storage temperature: -55 °C to 125 °C
Partner Modules
AW693
2x2 Dual-Band (5-7 GHz), 1x1 (2.4 GHz) Concurrent Dual Wi-Fi 6/6E and Bluetooth® 5.3 Combo Solution| Product | Wi-Fi I/F | Bluetooth I/F | Operating Temp | Antenna Type | Antenna # | Module Type | Module Size | Qualifications | Recommended Host |
|---|---|---|---|---|---|---|---|---|---|
|
AW-XMA06 |
PCIe | UART | -40 °C to +105 °C | Antenna pin(s) | 3 | Surface-mount device (SMD) | 23 x 23 x 2.58 | FCC | i.MX |
|
JODY-W683-01A |
PCIe, SDIO | UART, Pulse code modulation (PCM)/inter-integrated circuit sound (I²S) | -40 °C to +105 °C | Antenna pin(s) | 3 | SMD | 13.8 x 19.8 x 2.5 | AEC-Q104; FCC/ISED, RED/UKCA, GITEKI, BTSIG | i.MX 6/7/8/9 |
|
M2-JODY-W683-00C |
PCIe, Secure digital input/output (SDIO) | UART, PCM/I²S | -40 °C to +85 °C | U.FL connector(s) | 3 | M.2 card | 22.0 x 30.0 x 4.2 | AEC-Q104 subset; FCC/ISED, RED/UKCA, GITEKI, NCC, KCC, ANZ, BTSIG | i.MX 6/7/8/9 |
